VISION 5000 Videoconferencing System
29
General use
Microphone on/off
To switch your microphone on/off during a call, press the
MIC OFF
key. An on screen indicator will appear when
the microphone is off.
Pressing
MIC OFF
will mute audio inputs Mic1-3 and Audio4. It will not mute audio input from AUX and VCR
(Audio input 5&6).
Moving the picture-in-picture (PIP)
Press the
PIP
MOVE
key to move the Picture-in-Picture to different corners of the screen.
Controlling the Main Camera
Moving camera
To move the Main Camera, use the Camera Position keys, you must be outside the menu system to do
this.
UP
RIGHTOKLEFT
DOWN
Whenever you use the Camera Position, Focus or Zoom keys to control the Main Camera, a Picture-In-
Picture (PIP) will appear on the screen to show your image (provided the Auto-PIP feature is enabled and
you are not using a dual monitor system).
Zooming camera
To zoom in/out with the Main Camera, use the Zoom keys:
ZOOM
