Copier Bulletin: DIG-61
Date: 11/01/01
Page: 1 of 3
Models: e-STUDIO 28
Subject: SERVICE DOCUMENTATION
Copyright-2001 Toshiba America Business Solutions, Inc. (TABS). This publication contains proprietary and confidential information retained
for reference purpose by authorized TABS dealers. Unauthorized use of this information is prohibited. TABS makes no express or implied
warranty, including implied warranties of merchantability for a particular purpose, with regard to this technical publication and disclaims any
claim arising by reason of the possesion or use thereof.
Because the design of the e-STUDIO28 is based on the e-STUDIO35/45, a new
service manual will not be created. This bulletin describes the primary differ-
ences between the models.
In the tables below, the first number refers to the e-STUDIO45, the bracketed
[ ] number refers to the e-STUDIO35, and the number in parens { } refers to the
e-STUDIO28.
SERVICE MANUAL
Paper Cassette Bypass feeding PFP LCF
supply
Paper Size Size not (A4/LT only)
size specified specified
A4,LT,B5 45[35]{28} 45[35]{28} 21[18]{18} 45[35]{28} 45[35]{28}
A4-R 28[25]{25} 28[25]{25} 21[18]{18} 28[25]{25}
B5-R
A5-R
LT-R
ST-R
B4,LG 24[21]{21} 24[21]{21} 21[18]{18} 24[21]{21}
A3,LD 21[18]{18} 21[18]{18} 21[18]{18} 21[18]{18}
