1 BEFORE USING EQUIPMENT
28 Description of Each Component
Description of Each Component
Front / Right side
1. Reversing Automatic Document Feeder (Optional, MR-3018)
A stack of originals placed on this are scanned one sheet by one. Both sides of original can
be scanned. Maximum 100 sheets (20 lb. Bond), 80 sheets (28 lb. Bond) (or stack height
0.62") of originals can be placed in one go.
(The maximum number of sheets may vary depending on the media type of the originals.)
P.68 “Using the Reversing Automatic Document Feeder (optional)”
P.305 “Misfeed in the Reversing Automatic Document Feeder (optional)”
2. Operator’s Manual pocket (Back side)
Keep the Operator’s Manual in this.
3. Automatic duplexing unit
This is a unit to make copies on both sides of paper. Open it when paper jams occur.
P.311 “Misfeed in the automatic duplexing unit”
4. Bypass tray
Use this to make copies on special media types such as overhead transparencies, water-
proof paper.
P.81 “Bypass copying”
P.310 “Misfeed on the bypass tray”
5. Paper feed cover
Open this cover when releasing a paper misfeed in the drawer feeding area.
P.308 “Misfeed in drawer feeding area”
10
9
8
7
2
1
3
4
5
6
11
12
13
14
