4 Replacement Procedure 4.25 Fluorescent Lamp
4-86 TECRA M1 Maintenance Manual (960-436)
4.25.1 Replacing the 14.1-inch XGA TOSHIBA Fluorescent Lamp
CAUTION: When replacing the fluorescent lamp, wear finger covers or gloves to avoid
contaminating or damaging the LCD panel. Be careful not to let dust or other foreign
substance into the module.
Disassembling the 14.1-inch XGA TOSHIBA Fluorescent Lamp
To disassemble the 14.1-inch XGA TOSHIBA fluorescent lamp, follow the steps below and refer
to figures 4-51 to 4-55.
1. Removing tapes and insulation sheets from LCD module
1) Place the LCD module face down on a flat table that has no alien substance on it.
Make sure there is no dust on the desk to avoid scratching the surface of the LCD
module. Place a protective sheet (such as soft cloth) on the surface.
2) Remove the fixing tape for the FL cable, two tapes at the side of lamp, X-PCB
insulation sheet and Y-PCB insulation sheet from the LCD module in order as shown
in the figure below.
NOTE: 1) Be careful not to give any damage to the TAB.
2) The X-PCB insulation sheet should be left attached to the bezel, as it
will be recycled.
3) The Y-PCB insulation sheet shall not be disposed after removed, as it
will be recycled.
