4.4 Memory 4 Replacement Procedures
NB250/NB255 Maintenance Manual 4-13
4.4 Memory
Removing the Optional Memory
Remove the optional memory according to the following procedures and Figure 4.5 and 4.6 after
checking that the laptop is turned off.
CAUTION: Remove the optional memory after turning off the laptop. If this is violated, the
laptop or memory can be damaged.
1. Turn the laptop upside down.
2. Remove one M2.5Dx4 screw that secures the RAM door.
3. Remove the RAM door as shown in Figure 4.5.
CAUTION: Do not touch the connectors on the memory or in the laptop. Contaminated
connectors can cause memory access problems.
Figure 4.5 Removing the RAM door
M2.5Dx4*1
