4 Replacement Procedures 4.5 WLAN Card
NB250/NB255 Maintenance Manual 4-28
5. Close the laptop and secure two M2.5x6 screws as indicated in Figure 4.15.
6. Open the laptop and secure four 2.5x6 screws on the laptop as indicated in Figure 4.13.
7. Route first the WLAN antennas through the trough and then pull through the slot to the
underside of the computer.
8. Route the camera cable and microphone cable through the trough and secure in the logic
upper assembly with adhesive tape.
NOTE: Take extra care in routing cables and antennas on Logic upper assembly. Improperly
routed cables can become pinched or damaged and cause malfunction.
