Apx. C Pin Assignments Appendices
C.12 CN15 Cooling Module Connector (2) (3-Pin)
Table C-12 Cooling Module connector (2) pin assignments (3-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 +V5S - 2 DGND
-
3 /FAN_TACH2 I
C.13 CN16 Internal KEY Board Connector (34-Pin)
Table C-13 Key Board I/F connector pin assignments (34-Pin)
Pin No. Signal Name I/O Pin No. Signal Name I/O
1 +V5S - 2 NC -
3 NC - 4 NC -
5 NC - 6 +V5S -
7 /SCAN_OUT(4) O 8 /SCAN_OUT(2) O
9 /SCAN_IN(2) I 10 /SCAN_IN(1) I
11 /SCAN_OUT(1) O 12 /SCAN_OUT(0) O
13 /SCAN_IN(0) I 14 /SCAN_IN(3) I
15 /SCAN_OUT(5) O 16 /SCAN_OUT(6) O
17 /SCAN_IN(5) I 18 /SCAN_IN(6) I
19 /SCAN_IN(4) I 20 /SCAN_OUT(12) O
21 /SCAN_OUT(7) O 22 /SCAN_OUT(3) O
23 /SCAN_IN(7) I 24 /SCAN_OUT(13) O
25 /SCAN_OUT(9) O 26 /SCAN_OUT(8) O
27 /SCAN_OUT(11) O 28 /SCAN_OUT(10) O
29 /SCAN_OUT(14) O 30 /SCAN_OUT(15) O
31 +V5S - 32 /CAPS_LED#_3 O
33 /SCROLL_LED#_3 O 34 /NUM_LED#_3 O
Satellite A60/ Pro A60 Maintenance Manual C-1
