Pin Assignment
Satellite T110D / Satellite Pro T110D / PROTÉGÉ T110D Maintenance Manual (960-Q08)
9
61 GND --- 62 M_B_DQS#3 I/O
63 M_B_DM3 I/O 64 M_B_DQS3 I/O
65 GND --- 66 GND ---
67 M_B_DQ26 I/O 68 M_B_DQ30 I/O
69 M_B_DQ27 I/O 70 M_B_DQ31 I/O
71 GND --- 72 GND ---
73 M_CKE2 I/O 74 M_CKE3 I/O
75 +1.5VSUS --- 76 +1.5VSUS ---
77 NC --- 78 NC ---
79 M_B_BS#2 I 80 M_B_A14 I
81 +1.5VSUS --- 82 +1.5VSUS ---
83 M_B_A12 I 84 M_B_A11 I
85 M_B_A9 I 86 M_B_A7 ---
87 +1.5VSUS --- 88 +1.5VSUS ---
89 M_B_A8 I/O 90 M_B_A6 I/O
91 M_B_A5 I/O 92 M_B_A4 I/O
93 +1.5VSUS --- 94 +1.5VSUS ---
95 M_B_A3 I/O 96 M_B_A2 I/O
97 M_B_A1 I/O 98 M_B_A0 I/O
99 +1.5VSUS --- 100 +1.5VSUS ---
101 M_CLK_DDR2 I/O 102 M_CLK_DDR3 I/O
103 M_CLK_DDR#2 I/O 104 M_CLK_DDR#3 I/O
105 +1.5VSUS --- 106 +1.5VSUS ----
107 M_B_A13 I 108 M_B_BS#1
I
109 M_B_BS#0 I 110 M_B_RAS#
I
