DocuPrint N4525
Network Laser Printer
Productivity
without
Compromise
N4525 N4525DX N4525CN N4525FN
Print speed 45 pages per minute simplex; 39 images per minute duplex
First page out 4 seconds (ready mode); 7 seconds (standby mode)
Processor/DPL PowerPC 740 233MHz G3 Class RISC processor, Adobe PostScript 3, PCL6 and PCL5e emulations
Memory Standard / Maximum 32 MB / 192 MB RAM 32 MB / 192 MB RAM 64 MB / 192 MB RAM 64 MB / 192 MB RAM
Print resolution 1200 dpi Image Quality, 600 x 600 dpi, 300 x 300 dpi, Xerox Quad Dot halftoning, Xerox Image Enhancement
Standard network/connectivity 10/100BaseTX Ethernet, Bi-directional parallel, USB, (Token Ring, Serial, 10Base2 optional)
Automatic 2-sided printing Optional Standard Standard Standard
Paper input capability (2) 500 sheet trays (2) 500 sheet trays (2) 500 sheet trays (2) 500 sheet trays
50 sheet bypass feeder 50 sheet bypass feeder 50 sheet bypass feeder 50 sheet bypass feeder
Automatic 2-sided printing Automatic 2-sided printing Automatic 2-sided printing
2,500 sheet feeder 2,500 sheet feeder
Paper output capability 500 sheet face down 500 sheet face down 500 sheet face down 500 sheet face down
3,000 sheet finisher/stacker
with stapling and hole punching
Monthly duty cycle Up to 250,000 pages/month
Additional features Internal hard disk Internal hard disk
Warranty One year on-site, Xerox Total Satisfaction Guarantee
www.xerox.com/officeprinting
DocuPrint N4525 Network Laser Printer Specifications
Configurations
Specifications
Network/Software
Printer management Xerox CentreWare DP, CentreWare Internet
Services, Xerox PrinterMap, CentreWare Sun OS/Solaris Services,
SolarisReady certified, Microsoft certified, PrintXchange supported, VIPP
supported, SAP R/3, Tivoli OpenView, CA Unicenter, Microsoft Manage-
ment Console (MMC), SNMP-standard MIBs and Xerox extended MIBs
Font capabilities 35 Resident Adobe Type 1 fonts, 101
downloadable soft fonts, 45 PCL fonts, 10 Microsoft TrueType
fonts, 35 Intellifonts, 1 PCL compatible bitmap font
Printer drivers Windows 95/98/2000/Me and Windows NT 4.0,
OS/2 and OS/2 WARP, UNIX (Sun OS, Sun Solaris, HP/UX, IBM
AIX, SGI, DEC), Macintosh, Linus RedHat
Languages Genuine Adobe
®
PostScript
®
3™, PCL5e and PCL6
emulations with automatic sensing and switching. IBM AFP/IPDS
DIMM (Optional), TIFF 6.0 DIMM (optional)
Paper handling
Media types 17-53 lb (64-200gsm) bond and cardstock, coated
or glossy papers, labels, envelopes, transparencies
Media sizes letter, executive, legal, statement, folio, ledger, 8.5 x
5.5in, postcard, A3, A4, A5, A6, B4, B5. Edge-to-edge printing on
all paper sizes
Finisher (standard on FN model) 3,000 sheet Finisher/Stacker
with Stapling and Hole-Punching: up to 50 sheets stapled per set,
3 staple positions, hole-punching capability included.
Workset special features
Productivity tools for the user: Send Once, RIP Once, and Print
Many capability; Job pipelining to process multiple jobs concurrently;
MaiLinX – emails jobs to printer and sends alerts and status via email;
Proof Print
*
; Secure Print
*
; Draft/toner saver modes; Separator sheets
(for transparencies); Booklet printing; Auto tray select; Cover sheets;
Print Anyway; Variable fusing; Edge-to-edge printing; Load While Run;
Smart Jam Diagnostics; Fax-Friendly Black; N-Up (
*
needs hard disk)
Productivity tools for the IT manager: Web-based Printer
Administration via Embedded Web Server, MailLinX e-mail alerts,
PrinterMap, IPP support
Operating
Dimensions width: 25.3in/642mm, height: 19.1in/486mm,
depth: 21.3in/540mm, weight: 107lb/48.5kg (110V)
116lb/52.6kg (220V)
Environmental Temperature: 5˚ to 35˚C / 41˚ to 95˚F, Relative
Humidity: 15% to 85% (noncondensing), Noise Level: 28 dB(A)
standby, 55 dB(A) running
Electrical 110-127 VAC, 50/60 Hz, 220-240 VAC 50/60 Hz,
Sleep mode, Energy Star Compliant
Regulatory FCC Part 15, Subpart B, UL listed to UL 1950, Certified
to CSA—C22.2 No. 950, FDA 21 CFR Sub J, CE Mark applicable to
directives 73/23/EEC and 89/336/EEC, TUV - GS Mark, IEC 950
Second Edition (EN 6095, EN 60825)
Customer support
1-year On-site Warranty, online web technical support and telephone
support. The DocuPrint 4525 printer is backed by the Xerox
Total Satisfaction Guarantee.
Supplies
Consumables
Toner Cartridge 113R00195
(30K yield at 5% coverage)
Staple Cartridge 108R00158
3 cartridges, 5,000 staples per cartridge
Maintenance Kit 110V
(300K yield) 109R00048
contains: fuser cartridge, bias transfer roll,
15 feed rolls (3 for each paper input
tray), gloves, cleaning cloth, instructions
Options
2,500 sheet Feeder 097S02560
100 Envelope Feeder 097S02567
Duplex Module 097S02561
200 sheet Face-up Bin 097S02564
3000 sheet Finisher/Stacker with
Stapler and Hole Puncher
(3 hole position) 450S02180
Internal Hard Disk 097S02364
16-MB DIMM 097S02356
32-MB DIMM 097S02357
64-MB DIMM 097S02358
8-MB Flash DIMM 097S02360
TIFF DIMM 300N02591
IPDS DIMM 300N02593
Token Ring Interface Card
097S02363
Ethernet 10Base2 Interface Card
097S02362
RS232-C Serial Interface Card
097S02361
For media offerings, see our web
site: www.xerox.com
For the location of your nearest Xerox reseller, or for more information, visit our
Web site or call: United States and Canada 1-877-362-6567 Europe (UK) +44
870 241 0921, other regions see your local Xerox or Fuji/Xerox representative.
XEROX
®
, The Document Company
®
, CentreWare
®
, DocuPrint
®
, PrinterMap, WorkSet
®
, and N4525 are trademarks of XEROX CORPORATION.
Solaris™Ready, the Solaris™Ready logo, SunOS™, and Solaris™ are trademarks of Sun Microsystems Inc. in the US and other countries. As an ENERGY
STAR
®
Partner, Xerox has determined that this product meets the ENERGY STAR
®
guidelines for energy efficiency. Other product and/or company names
used herein are trademarks of their respective owners. Product appearance and/or specifications subject to change without notice. 3/01 BT 452BR-01UA
