User Manual
1 GENERAL INFORMATION
• High-speed symmetrical data transmission over one physical copper
twisted pair with the 135 Ohm impedance according to ETSI TS 101 135.
• ITU-T G.991.2 (G.shdsl) line encoding.
• Line rate in the range from 72 Kbit/s to 2320 Kbit/s in 2 wire mode
Line rate in the range from 144 Kbit/s to 4624 Kbit/s in 4 wire mode
• Manual or automatic mode of line-speed adjustment.
• Ethernet 10/100Base-T interface, Full/Half duplex.
• Transmition of VLAN packet (IEEE-802.1Q).
• Dynamic table formation of MAC addresses.
• Accumulation of up to 1024 MAC addresses.
• Granting of 95% of the digital channel band to the user.
• In-built functions of diagnostics and self-testing.
• Low power consumption, easy-to-use applications.
• Console port for the local management.
• Telnet port for the local / remote management
• 220 Vac power
For MDS932AE-FXO/FXS
• up to 2 voice cannel.
Version: 1.2 Page. 6 of 25
