Outdoor Access Points
Model DWL-2700AP
IEEE Wired Standard 802.3;802.3u;802.3af
Ethernet Interface 10/100BASE-TX(PoE)
IEEE Wireless Standard 802.11b;802.11g
Data Transfer Rate
802.11a -
802.11b 11,5.5,2,1Mbps
802.11g 54,48,36,24,18,12,9,6Mbps
802.11n -
FrequencyRange
5GHz -
2.4GHz 2.4GHzto2.4835GHz
RFChannel
5GHz -
2.4GHz UnitedStates:11;Europe:13;Japan:13
Radio and
ModulationType
802.11a -
802.11b DSSS,DQPSK,DBPSK,CCK
802.11g OFDM,BPSK,QPSK,16QAM,64QAM
802.11n -
Transmitter Output
Power(Typical)
802.11a -
802.11b 23dBm@1~11Mbps
802.11g 23dBm@6~54Mbps
Receiver Sensitivity
802.11a -
802.11b
-91dBm@1Mbps
-90dBm@2Mbps
-89dBm@5.5Mbps
-84dBm@11Mbps
802.11g
-85dBm@6Mbps
-84dBm@9Mbps
-82dBm@12Mbps
-80dBm@18Mbps
-77dBm@24Mbps
-73dBm@36Mbps
-69dBm@48Mbps
-68dBm@54Mbps
802.11n(2.4GHz) -
802.11n(5GHz) -
OperationModes AccessPoint;WDS;WDSwithAP
Antenna
AntennaGain 5dbi
No. of Antennas 2
Antenna Type
Detachable Dipole Antennas with
RN-PNTypeConnectors
Physical &
Environment
Dimension(mm)
277.7x155x45
(LxWxH)
Weight 1.82 kg
Outdoor
Installation
IP68Standard;DiecastWatertightHousing
Built-inHeaterwithSensor
Power Input ViaExternalPowerAdapter
Operating/
Storage
Temperature
-40to60°C/-40to65°C
Operating/
Storage
Humidity
10%to90%Non-Condensing/5%to95%Non-Condensing
Certication
EMI-EMC
Compliance
FCC;CE;C-Tick
Safety
Compliance
CSA
Wi-Fi
®
Yes
BUSINESS WIRELESS Outdoor Access Points
