50 BUSINESS WIRELESS
UniedSwitch-DWS-4000Series
Model DWS-4026
IEEE LAN Standard 802.3;802.3u;802.3z;802.3ab;802.3ae;802.3af
Port
Interface
10/100/1000
BASE-T(RJ-45)
20(PoE)
Combo
1000BASE-T/SFP
4
10GESlot 2
XFPModule DEM-410X
CX4Module DEM-410CX
Physical Stack
ViaCX4/XFPModule;DuplexChain/RingTopology;
Bi-DirectionalRedundantStackingTopology;
Upto40Gbps(FullDuplex);Upto12UnitsPerStack
General
Features
SwitchCapacity 88Gbps
ForwardingRate 65.47Mpps(Maximum)
Forwarding
Mode
StoreandForward
BuerMemory 750KBytes
MTBF 185,540hours
ConsolePort FemaleRS-232DB-9ConsoleforOut-of-BandConguration
WLANManagement
Capability
Max.64APsPerSwitch;Max.256APsPerCluster;
Max.2048WirelessUsers(1024Tunneled,2048Non-Tunneled)
Roaming
FastRoaming(WirelessAdapterneedstosupporttoo)
Intra-Switch/Inter-SwitchRoaming;
Intra-Subnet/Inter-SubnetRoaming;AP-AP-Tunnel
AccessControl&Bandwidth
Management
Max.32SSIDPerAP(16SSIDPerRFFrequencyBand);
APLoadBalancingbasedontheNo.ofUsersorUtilizationPerAP
ManagedAccessPoint DWL-8600AP
APManagement
APAuto-Discovery;RemoteAPReboot;
APMonitoring:ListManagedAP,AuthenticationFailedAP,
RogueAP;Ad-HocClientsMonitoring;
ClientMonitoring:ListClientsAssociatedwithEachManagedAP;
APAuthenticationSupportingLocalDatabaseandExternal
RADIUSServer;CentralizedRF/SecurityPolicyManagement;
VisualizedAPManagementTool(Supportupto16JPGFiles);
UniedAPSupport(DWL-8600AP):Managed/StandaloneMode
WLAN Security
WirelessIntrusionDetection&PreventionSystem(WIDS);
RogueAPMitigation;64/128-bitWEPDataEncryption;
RogueandValidAPClassicationbasedonMACAddress;
WPAPersonal/Enterprise;WPA2Personal/Enterprise;
WirelessStationandAPMonitoringonRFChannel,
MACAddress,SSID,Time;CaptivePortal;StationIsolation;
EncryptionTypeSupport:WEP,WPA,DynamicWEP,TKIP,
AES-CCMP,EAP-FAST,EAP-TLS,EAP-TTLS,EAP-MD5,
PEAP-GTC,PEAP-MS-CHAPv2,PEAP-TLS;MACAuthentication
L2Features
MACAddressTableSize:8KEntries;
IGMPSnooping:1KMulticastGroups;MLDSnooping;
802.1DSTP,802.1sRapidSTP,802.1wMultipleSTP;
802.3adLinkAggregation:Max.32Groups,
Max.8PortsPerGroup;JumboFrame:Max.9KBytes;
802.1abLinkLayerDiscoveryProtocol(LLDP);LLDP-MED;
PortMirroring:One-to-One,Many-to-One;
FlowControl:802.3xinFullDuplex,BackPressurein
HalfDuplex,Head-of-LineBlockingPrevention
VirtualLAN(VLAN)
802.1QTaggedVLAN;802.1vProtocolVLAN;
VLANGroups:Max.3,965Entries;Subnet-basedVLAN;
GARPVLANRegistrationProtocol(GVRP);
MAC-basedVLAN;DoubleVLAN;VoiceVLAN
L3Features
IPv4StaticRoute;RoutingTableSize:Max.128StaticRoutes;
FloatingStaticRoute;ProxyAddressResolutionProtocol(ARP);
VirtualRouterRedundancyProtocol(VRRP);
RoutingInformationProtocol(RIP)v1/v2
QualityofService(QoS)
802.1pPriorityQueues(Max.8QueuesPerPort);Auto-VoIP;
MinimumBandwidthGuaranteePerQueue;
TracShapingPerPort;Per-FlowBandwidthControl;
CoSbasedon:SwitchPort,VLAN,DSCP,TCP/UDPPort,TOS,
Dest/SourceMACAddress,Dest/SourceIPAddress
AccessControlList(ACL)
ACLbasedon:SwitchPort,MACAddress,802.1pQueues,VLAN,
EtherType,DSCP,IPAddress,ProtocolType,TCP/UDPPort
LAN Security
RADIUS&TACACS+AuthenticationforManagementAccess;
SecureShell(SSH)v1/v2;SecureSocketsLayer(SSL)v3;
TransportLayerSecurity(TLS)v1;MACFiltering;
DenialofServiceProtection;DynamicARPInspection(DAI);
PortSecurity:20MACPerPort,PortViolationNotication;
802.1XPort-basedAccessControlandGuestVLAN;
BroadcastStormControlinGranularityof1%ofLinkSpeed;
DHCPSnooping;ProtectedPort;DHCPFiltering
ManagementMethods
Web-basedGUI;SwitchClustering;RADIUSAccounting;
CommandLineInterface(CLI);TelnetClient;TFTPClient;
TelnetServer:Max.5Sessions;sFlow;BootP/DHCPClient;
DHCPServer;DHCPRelay;DualImages;PortDescription;
MultipleCongurationFiles;DualImageServices;
SimpleNetworkManagementProtocol(SNMP)v1/v2c/v3;
RemoteMonitoring(RMON)v1;
SimpleNetworkTimeProtocol(SNTP);SystemLog
Physical &
Dimension 19-inch;1URack-Mount;440x389x44mm(WxDxH)
Weight 6kg
Power Input Input:100-240VAC,50/60Hz;InternalUniversalPowerSupply
Max.Power
Consumption
525W(WithAllPoEPortsinOperation)
PoE PowerBudget:370A;PerPort:15.4W
RPS DPS-600
Temperature 0to40°C(Operation);-10to70°C(Storage)
Humidity 10%~90%(Operation);5%~90%(Storage)Non-Condensing
EMI-EMC FCCClassA;CE;VCCI;C-Tick;ICES-003;EN606011-2
Safety UL/cUL;CB
UniedAccessPoint-DWL-8600AP
Model DWL-8600AP
IEEE Wired Standard 802.3;802.3u;802.3ab;802.3af
IEEE Wireless Standard 802.11a;802.11b;802.11g;802.11n
Data
Transfer
Rate
802.11a 54,48,36,24,18,12,9,6Mbps
802.11b 11,5.5,2,1Mbps
802.11g 54,48,36,24,18,12,9,6Mbps
802.11n Upto300Mbps
Wireless
Frequency
Range
802.11a
5.15GHzto5.35GHz
5.47GHzto5.825GHz
802.11b/g 2.4GHzto2.4835GHz
802.11n
2.4GHzto2.497GHz
4.9GHzto5.85GHz
RFChannel
5GHz
US&Canada:12;Europe:19;
Japan:8;China:5(Non-Overlapping)
2.4GHz US:11;Europe:13;Japan:13
Radio and
Modulation
Type
DBPSK@1Mbps;DQPSK@2Mbps;
CCK@5.5/11Mbps
802.11a/g
(OFDM)
BPSK@6/9Mbps;QPSK@12/18Mbps;
16QAM@24/36Mbps;
64QAM@48/54Mbps
802.11n PSK/CCK,DQPSK,DBPSK,OFDM
Transmit
Output
Power
(Typical)
802.11a
17dBm@6/9/12/18Mbps;
15dBm@24/36Mbps;
14dBm@48Mbps;13dBm@54Mbps
802.11b 17dBm@1/2/5.5/11Mbps
802.11g
17dBm@6/9/12/18Mbps;
16dBm@24/36Mbps;
15dBm@48Mbps;14dBm@54Mbps
802.11n
5GHzBand/HT-20:12to17dBm;
5GHzBand/HT-40:11to16dBm;
2.4GHzBand/HT-20:13to17dBm;
2.4GHzBand/HT-40:12to16dBm
Receiver
Sensitivity
802.11a
-87dBm@6Mbps;-86dBm@9Mbps;
-84dBm@12Mbps;-81dBm@18Mbps;
-77dBm@24Mbps;-75dBm@36Mbps;
-68dBm@48Mbps;-67dBm@54Mbps
802.11b
-92dBm@1Mbps;-90dBm@2Mbps;
-88dBm@5.5Mbps;-84dBm@11Mbps
802.11g
-87dBm@6Mbps;-87dBm@9Mbps;
-85dBm@12Mbps;-82dBm@18Mbps;
-79dBm@24Mbps;-76dBm@36Mbps;
-71dBm@48Mbps;-70dBm@54Mbps
802.11n
5GHzBand/HT-20:-82to-64dBm;
5GHzBand/HT-40:-79to-61dBm;
2.4GHzBand/HT-20:-85to-67dBm;
2.4GHzBand/HT-40:-82to-63dBm
Antennas
4DualBandDetachableDipole
Antennas
withReverseSMAConnectors
Antenna
Gain
6dBifor5GHzBand;4dBifor2.4GHz
Band
Ethernet Interface
10/100/1000BASE-T Port with
802.3afPoweroverEthernet(PoE)
CongurationOperation
Modes
AccessPointOnly;
WirelessDistributionSystem(WDS);
Access Point with WDS
Security
64/128/152-bitWiredEquivalent
Privacy;
MACAddressFiltering:Local/RADIUS;
Wi-FiProtectedAccess(WPA)/WPA2
ExtensibleAuthenticationProtocol
(EAP);
WPA/WPA2Pre-SharedKey(PSK);
TemporalKeyIntegrityProtocol(TKIP);
AdvancedEncryptionStandard(AES);
802.1QSSIDBroadcastEnable/Disable;
16SSIDPerFrequencyBand;
32SSIDPerAP;802.11i/WPA2;
RADIUS:Max.4ExternalRADIUS
Servers;
IsolatedSecurityforEachSSID;
StationIsolation;IEEE802.1X
Supplicant
ManagementMethods&
Protocols
ProtocolsSupportedinDWS-4026;
HTTP/HTTPS;SSH;SNMP;Syslog;Telnet
Physical &
Dimension 190.5x198.8x36.8mm(LxWxH)
Weight 1.02kg
Power
Input
Via48VDC,0.4AExternalPower
Adapter
OperatingVoltage:48VDC+/-10%
for PoE
Power
11WwithPoE;12WwithPoE
(Maximum)
Operation 0to40°C
Storage -20to65°C
Operation
Humidity
10%to90%(Non-Condensing)
Storage
Humidity
5%to95%(Non-Condensing)
Certication
FCCClassB;CE;C-Tick;VCCI;TELEC;
Wi-Fi;ICES-003;EN60601-1-2;
NCC;CSAInternational
Unied Wired/Wireless Access System
