71 IP SURVEILLANCE Fixed Network Cameras
Fixed Network Cameras
Model DCS-3430 DCS-3710 DCS-7410 DCS-7510
IEEE Standard
Wired 802.3,802.3u 802.3,802.3u,802.3af
Wireless 802.11n,802.11g -
WiredNetwork
Port Interface 10/100BASE-TX
Power over Ethernet - Yes
Wireless
Network
Frequency Range 2.412~2.4835GHz -
Data Rate
802.11n:MCS0~MCS15
802.11g:6~54Mbps
-
Antenna 2dBiDipole -
Camera
Specification
Image Sensor 1/4”CMOS
1/3”1.3MegapixelWDR
ProgressiveScanCMOS
1/3”ColorCCD 1/3”ColorCCD
Lens CSMount Vari-Focal, DC Iris Fixed Vari-Focal Auto Iris
Focal Length 6mm 2.8~12mm 12mm 9~22mm
F-Number F1.8 F1.3 F1.4 F1.5~360
MinimumIllumination
0.5Lux(typical)
0Lux(10mwithIRLens)
0.1Lux(Color)
0.02Lux(B/W)
0.7Lux 1Lux
AngleofView(Horizontal) 41° 102.2°~23.7° 22° 31°~13°
AngleofView(Vertical) 31° - 17° 23°~10°
Digital Zoom 16x 10x 16x 16x
Optical Zoom - - - -
Day & Night IR Cut Removable Filter IR Cut Removable Filter
Dual-BandFilter
IRLEDs(30m)
IR Cut Removable Filter
IRLEDs(50m)
Video
Management
Video Format H.264/MPEG-4/MJPEG MPEG-4/MJPEG MPEG-4/MJPEG MPEG-4/MJPEG
Dual Stream - - - -
Multi-Prole Yes Yes Yes Yes
VideoBitRate 64kbps~2Mbps 64kbps~8Mbps 64kbps~2Mbps 64kbps~2Mbps
Max.VideoResolution
704x480(NTSC)
704x576(PAL)
1280x960
720x480(NTSC)
720x576(PAL)
720x480(NTSC)
720x576(PAL)
FrameRate(fps) 30(NTSC);25(PAL) 30 30(NTSC);25(PAL) 30(NTSC);25(PAL)
WideDynamicRange
(WDR)
- Yes - -
Automatic Electronic
Shutter
Yes Yes Yes Yes
AutomaticGainControl Yes Yes Yes Yes
AutomaticWhiteBalance Yes Yes Yes Yes
Electronic Shutter
(Seconds)
1/60~1/100,000(NTSC)
1/50~1/110,000(PAL)
1/2~100,000
1/60~1/100,000(NTSC)
1/50~1/110,000(PAL)
1/60~1/100,000(NTSC)
1/50~1/110,000(PAL)
CongurablePrivacyMask - 3Zones - -
Flip&Mirror Yes Yes Yes Yes
MobileVideo 3GPP 3GPP 3GPP 3GPP
MonitorOutput BNC BNC BNC BNC
Audio
Management
2-WayAudio Yes Yes Yes Yes
Built-inMicrophone Yes - - -
ExternalMicrophone
(LineIn)
Yes Yes Yes Yes
External Speaker
(LineOut)
Yes Yes Yes Yes
Audio Recording Yes Yes Yes Yes
Audio Codec GSM-AMR/ADPCM ADPCM GSM-AMR/ADPCM GSM-AMR/ADPCM
Sampling Rate
GSM-AMR:12.2kbps
ADPCM:8kbps
ADPCM:8kbps
GSM-AMR:12.2kbps
ADPCM:8kbps
GSM-AMR:12.2kbps
ADPCM:8kbps
Audio Frequency 20~20,000Hz 20~20,000Hz 20~20,000Hz 20~20,000Hz
AudioMute Software Software Software Software
Event
Management
MotionDetection Yes Yes Yes Yes
Event Triggered Recording Yes Yes Yes Yes
Email Alarm Notification Yes Yes Yes Yes
Pre/PostAlarmBuffer - Yes - -
Storage
Management
Direct to NAS Yes Yes Yes Yes
Direct to Card Slot Yes Yes - -
External Card Slot SD Card SD Card - -
I/OConnector
DigitalInput/Digital
Output(DI/DO)
2/1 2/1 2/1 2/1
RS-485Interface Yes Yes Yes Yes
Outdoor Usage -
WithOutdoorEnclosure
DCS-45/DCS-50/DCS-60
IP66CertiedWeatherProofCasing
Physical and
Environment
Dimension(WxDxH) 78x177x60mm 80x140x53mm 8.79x240x84.1mm 8.79x240x109.1mm
Weight 577.8grams 576grams 1.63kg 1.72kg
Power Input Via External Power Adapter
Via External Power Adapter or
PoweroverEthernet(PoE)
Max.PowerConsumption 6.9W 2W 7.88W 7.95W
Power over Ethernet
(IEEE802.3af)
PoE Splitter Required
2
Class2/3
1
Class2/3
1
Class2/3
1
Operating Temperature 0to40°C
Storage Temperature -20to70°C
Humidity 20%to80%Non-Condensing
Certification FCC, CE, C-Tick, IC, LVD FCC, CE, C-Tick FCC, CE, C-Tick, IC FCC, CE, C-Tick, IC
1
Include Power Output for External Devices
2
PoESplitter-DWL-P50(RefertoNetworkPeripheral-PowerOverEthernetSection)
