71 IP SURVEILLANCE Video Encoders
Video Encoders
Model DVS-210-1
Network Specifications
LocalAreaNetwork(LAN) One10/100BASE-TXRJ-45
Network Protocols
TransmissionControlProtocol/InternetProtocol(TCP/IP);
DynamicHostCongurationProtocol(DHCP);HyperTextTransferProtocol(HTTP);
DynamicdomainNameSystem(DDNS);NetworkTimeProtocol(NTP);FileTransferProtocol(FTP);
SimpleMailTransferProtocol(SMTP);UserDatagramProtocol(UDP);RealTimeProtocol(RTP);
RealTimeStreamingProtocol(RTSP);UniversalPlug-and-Play(UPnP)
Video Specifications
Video Format MJPEGandMPEG-4SimultaneousDualCodec
Frame Rate NTSC:30fps;PAL:25fps
BitRate 64kbpsto4Mbps
Resolution
NTSC:720x480(D1),352x240(CIF),176x120(QCIF)
PAL:720x576(D1),352x288(CIF),176x144(QCIF)
Video Input 1CH;NTSC/PAL;BNCConnector;1.0Vp-pwith75Ω loading
Video Recording Instant Local Video Recording
VideoBuffer Pre/PostBufferforImage/VideoCapture
Audio Specification
Audio Input 8kHzSampleRate;AdaptiveDifferentialPulse-CodeModulation(ADPCM)
Audio Output 8kHzSampleRate;AdaptiveDifferentialPulse-CodeModulation(ADPCM)
Audio Connector 3.5mmStereoInput/Output
Audio Direction Bi-DirectionalAudio
Pan/Tilt/ZoomSpecication
PTZ Protocols PelcoP;PelcoD;MeritLilin;Visca;DynaColor;Transparent
BaudRate 1200,1800,2400,4800,9600,19200
PTZ Connector RS-485forPTZControl
AlarmHandling
Loss Detection Video and Network Loss Detection
MotionAlarm Built-inMotionAlarmwithCongurableDetectionAreas
EventHandler FTPandE-mailEventHandler
Storage Local Storage StorevideotoremovableSDCard(LocalSDCardSlot)
MinimumSystem
Requirement
CentralProcessingUnit(CPU) Pentium4,2.4GHzandabove
HardDisk 40GBorhigher
Memory 512MBorhigher
Operating System Windows7/WindowsVista/WindowsXPSP2orhigher/Windows2000SP4orhigher
Video Resolution 1024x768(SVGA/XGA)
Software DirectX9.0corhigher
Browser MicrosoftInternetExplorer6.0orhigher
Physical and Environment
Dimension(LxWxH) 90x78x36mm
Weight 232gram
Power Input Via External Power Adapter
Operating Temperature 0°Cto40°C
OperatingHumidity 20%to80%Non-Condensing
