System Capacity
MGC-50
™
Maximum number of IP ports 72*
Ports can be increased by cascading multiple MGC systems
Maximum number of simultaneous conferences 24
Maximum number of Continuous Presence conferences 8
SUPPORTED IP PROTOCOLS
Videoconferencing • H.323
Communications • H.245
Video • H.261, H.263, H.263+
Audio • G.711, G.722, G.722.1,G.723, G728, Siren 7 (16, 24, 32Kbps)
SUPPORTED ISDN/ATM PROTOCOLS (optional)
Videoconferencing • H.320, H.321,T.120
Telephony • H.320
Multi-way • H.231, H.243 Cascading and Chair Control
• H.281 FECC (Far End Camera Control)
Video • H.261, H.263, H.263+, H.263
Audio • G.711, G.722, G.722.1, G.728 ,Siren 7 (16, 24, 32Kbps)
Data • H.243 LSD,T.122/T.125 (MCS),T.123,T.124 (GCC)
Communications • H.221, H.242
Channel aggregation • H.221, BONDING Mode 1, H0
SUPPORTED INTERFACES
Standard interface: H.323 • 10/100Mbps Ethernet
Optional Interfaces: H.320 • PRI-T1, PRI-E1, E1/T1 Leased line,V.35/RS-449/EIA-530
with RS-366 dialing, KG (encryption) support
H.321 • 25Mbps, 155Mbps (OC3)
EXTERNAL COMMUNICATIONS
Data Rates H.323 • Up to 1.5Mbps
H.320 • Up to 1.5/2.0Mbps (56 and 64Kbps channels)
H.321 • Up to 1.5Mbps
Clock Synchronization • Internal clock or external network
ENVIRONMENT
Operating Temperature • 10˚ to 40º˚ C (50˚ to 104º˚ F), 3400 BTU per hour
Storage Temperature • -40˚ to 70˚ ºC (-40˚ to 158º˚ F)
Relative Humidity • 15 to 90% non-condensing
Operating Altitude • Up to 3,000 m (10,000 ft)
Storage Altitude • Up to 12,000 m (40,000 ft)
Operating ESD • +8 kV
Storage ESD • +15 kV
Physical Dimensions
Height 40.8cm (16 inches) Width 38.1cm (15 inches)
Depth 50.2cm (19 inches) Power 120-230VAC, 50/60Hz
Weight Net 30kg (66lbs), Optional 19 inch rack mount kit
including packaging 52kg (110lbs)
* Available second half 2001
