11.2.2LAN-USB_X2
NOTE: Pins 9-18 for RJ-45 LAN Jack pin definition, 19-22 for LAN LED definition
Pin Signal Name
"1, 5" VCC_USB0 (5V)
2 USBP7N_R
3 USBP6N_R
"4, 8" GND
6 USBP6N_R
7 USBP6P_R
"23,24,25,26,
27,28,29,30"
Ground
9 AVDD18
10 MDI0+
11 MDI0-
12 MDI1+
13 MDI1-
14 MDI2+
15 MDI2-
16 MDI3+
17 MDI3-
18 GND
19 ACT_LED
20 LAN_LINK_LED
21 100_LED
22 1G_LED
