Creative Solutions for the Digital Life
™
HPNA Adapter
Technical Specifications Minimum System Requirements
• Router, Gateway, or other device with HPNA 3.1 capability
• Microsoft Windows 2000, XP or Vista
• TCP/IP Network Protocol Installed
• Internet Explorer 4.0+ or Netscape 4.0+
Package Contents
• Ethernet to Coax HPNA Adapter
• Power adapter
• Quick Start Guide
• Ethernet Cable
Corporate Office
760 N. Mary Avenue,Sunnyvale, CA 94085
Main: (408) 752-7700
Sales Info: (800) 797-7001
Fax: (408) 541-9003
Tech Support: (888) 436-0657
Tech Support Fax: (719) 522-9421
Internet: www.actiontec.com
©2008ActiontecElectronics,Inc.
Actiontec,ActiontecInstallationBuddy,Connection1-2-3,CreativeSolutionsfortheDigitalLife,
ActiontecDigitalGearandtheActionteclogoaretrademarksorregisteredtrademarksof
ActiontecElectronics,Inc.Allothernamesarepropertiesoftheirrespectiveowners.
Productphotomaydifferfromactualproduct,howeverfunctionalityremainsasstatedabove.
Specificationsaresubjecttochangewithoutnotice.
DS960/0508
Features
InterfacePorts
FrontPanel
LEDFunction
Enclosurephysical
dimensions
EthernetPorts
Power
Requirements
Environmental
OperatingRange
Required
Regulatory
Approvalsand
Compliance
Descriptions
•
Two Type F portsforthe HPNACoaxial cableand a
Set-topBox
•
Two RJ-45ports10/100Base-TEthernet LAN
•
One5V DC1.5Apowerport
•
Eightvisual indicators:Ethernet(2),SYNC,HPNA,
PC/LAN,STB/MODEM,POWER,STB/TV
SYNC
SolidGreen: HPNA hostis detected
Off:Poweroff , HPNA hostis notdetected
HPNA
SolidGreen: HPNA linkis established
Off:Poweroff , HPNA linkis notestablished
PC/LAN
SolidGreen:EthernetlinkisestablishedonthePC/LANport
Off:Ethernet link is disconnectedor devicepoweroff
STB/MODEM
SolidGreen: Ethernetlinkis establishedon the
STB/MODEM port
Off:Ethernet link is disconnectedor devicepoweroff
Power
SolidGreen: Poweris being applied tobridge
SolidRed:Bridge malfunctions orPowerfail
Off:Poweroff
STB/TV
Type F connectorconnects toa set-top
Length:5 inch
Width: 3 inch
Height:1 inch
•
Compliantwith IEEE 802.3and IEEE 802.3u.
•
SupportsAuto-MDIX.
•
Dual 10/100RJ-45 Ethernet portsto support multiple
IPdevicesper bridgeincluding PCsand DSLmodems
•
Operatingvoltage: +5V+/-10%
•
PowerDissipation:5V DC @ 1000mA (Max)
•
Operatingtemperature:-5~50 degrees Celsius
•
Humidity:8-95%,non-condensing
•
EMI/Immunity:FCC part15 Class B
•
UL
