Filter
Top Products
LCD DISPLAY
ARM
WIRELESS R/F KEY-
BOARD & MOUSE
TV TUNER
FRAME
WALL MOUNT
KIT
Optional Accessories
F-Series Displays
Panel
Panel Type
Panel Size
Max. Resolution
Pixel Pitch
Brightness
Contrast Ratio
Surface Treatments
Viewing Angle (H/V)
Wide Viewing Angle
Display Color
Response Time
CCFL
Life Time (Hours)
RGB Analogue
Frequency
Sync
Max. Pixel Clock
Signal System
Input Level
Analog
Video (Option)
Speaker
Power
Input Level
Audio-In
Audio-Out
Speakers
Amplifier
SRS
Audio Processor Effects
Tilt Angle / Swivel
VESA FPMPMI
Net (W x H x D)
Packing (W x H x D)
Net Weight
Gross Weight
Safety & EMI
VESA
Power AC
Consumption
TFT LCD
15.0" (381mm)
XGA 1024 x 768
0.297mm
350cd/m
2
(Typical)
500:1 (Typical)
Hard Coating (3H),Anti-glare
treatment, Anti-static
170°/170° (Minimum)
Yes
16.7M
15ms /10ms (Typical)
4
50,000 (typical)
0.714 Vp-p @ 75 ohm
Horizontal: 30kHz - 60kHz
Vertical: 50Hz - 75Hz
TTL level
80MHz
NTSC, PAL, SECAM
1Vp-p @ 7ohm
15-Pin Mini D-Sub
4-Pin Mini Din S-Video
CVBS Jack
Component Video
Yes (2W)
3-Pin AC Plug
Max: 1 Vp-p rms
3.5mm audio line-in
3.5mm headphone jack
Two 2 watt built-in speakers
1.5W at 1kHz
SRS
3D Stereo
0°~ 20° (Tilt)
Yes (100mm)
416 x 364 x 160mm
(16.4" x 14.3" x 6.3")
465 x 420 x 150mm
(18.3" x 16.5" x 5.9")
3.7Kg (8.2lb)
5.9Kg (13.0lb)
FCC, UL/CUL, EPA, TUV/GS,
CE, NORDIC, NUTEK, BSMI,
VCCI, CCIB,CB, ISO13406,
TCO95 or TCO99
(depends on color)
DDC1/2B, DPMS
100~240V, 50~60Hz
< 48W (On) < 5W (Stand-by)
< 5W (Off)
TFT LCD
17.0" (432 mm)
SXGA 1280 x 1024
0.264mm
250cd/m
2
(Typical)
500:1 (Typical)
Hard Coating, Anti-glare
treatment, Anti-static
170°/170° (Minimum)
Yes
16.7M
15ms /10ms (Typical)
4
50,000 (min)
0.714 Vp-p @ 75 ohm
Horizontal: 30kHz -80kHz
Vertical: 50Hz - 75Hz
TTL level
140MHz
NTSC, PAL, SECAM
1Vp-p @ 7ohm
15-Pin Mini D-Sub
4-Pin Mini Din S-Video
CVBS Jack
Component Video
Yes (2W)
3-Pin AC Plug
Max: 1 Vp-p rms
3.5mm audio line-in
3.5mm headphone jack
Two 2 watt built-in speakers
1.5W at 1kHz
WOW
by SRS
0°~ 20° (Tilt)
Yes (100mm)
474 x 408 x 187mm
(18.6" x 16.1" x 7.4")
565 x 522 x 178mm
(22.2" x 20.5" x 7.1")
4.9Kg (10.8lb)
6.9Kg (15.2lb)
FCC, UL/CUL, EPA, TUV/GS,
CE, NORDIC, NUTEK, BSMI,
VCCI, CCIB, CB, ISO13406,
TCO95 or TCO99
(depends on color)
DDC1/2B, DPMS
100~240V, 50~60Hz
< 48W (On) < 5W (Stand-by)
< 5W (Off)
F-315Specifications F-317
All specifications are subject to change without prior notice. © 2003 Associated Industries China Inc.
The name AG Neovo is a trademark of AIC. All other trademarks are the property of their respective owners.
DM Code: MKT-FM57E-0303
Video In Port
Connect DVD, VCR or other
video devices directly via a
video in port.
Built-in Speakers
Eliminate the need for exter-
nal speakers, and enjoy a rich
multimedia experience.
Picture-In-Picture
Watch computer display and
DVD, VCR or other video
simulataneously.
WOW Technology
Produces a taller and wider
soundstage with enhanced
bass performance (F-317).
Auto-Adjustment
Automatically adjusts screen
settings for an optimal image,
without changing settings
manually.
OSD
On-Screen Display (OSD)
makes adjusting the display set-
tings quick and convenient.
LCD Display Arm
Advanced gas-spring suspen-
sion guarantees smooth stable
operation, and flexibility of use.
Wall Mount Kit
Mount the LCD display on the
wall to save even more valu-
able desktop space.
Cable Management
Built In cable management sys-
tem promotes a clutter-free
and more organized desktop.
Security Lock
Increase security by anchor-
ing the LCD display to an im-
movable object. Compatible
with Kensington
®
security
locks.
SRS 3D Technology
Delivers a panoramic 3D
soundstage from ordinary
audio input (F-315).
VGA
Analogue
Input Signal
Video Input
Mounting
Dimensions
Weight
Regulation
Approval
Power
Tilt/Swivel
Connector
Audio
