4
Parts Identification
Front view
1. Remote control receiver window
2. Picture frame
Back view
· DC 9V IN (for power input)
· ANT INPUT (for antenna signal input)
· VIDEO OUTPUT (for video signal output)
· AUDIO OUTPUT (for audio signal output)
DC 9V IN
VIDEO
ANT
INPUT OUTPUT
AUDIO
OUTPUT
This device complies with Part 15 of the FCC
Rules.Operation is subject to the following two
conditions:(1)this de vice may not cause harmful
interference,and(2)this dev ice must accept any
interference received,inc luding interference that
may cause undesired operation.
MADE IN TAIWAN.
MODEL NO.: TV-01
XXXXXXXX
0XX00001
Associated Industries China, Inc.
S/N:FTB
檢磁
9V/500mAInput:
Gruppe
TUVRheinland
TYPE
BAUART
GEPRUFT
APPROVED
Ly
5
Remote controller
1 0…9, 100: for direct channel selection
2 CH▲▼: channel selection
3 VOL▲▼: volume control
4 RETURN: return to last selected channel
5 CH +/-: to add or erase channel
6 TV/CATV: select TV or cable TV
7 MUTE: to enable/disable the audio mute function
8 MTS: to select audio mode (mono/stereo/sap)
(This function is only feasible for NTSC system.)
9 SCAN: to scan the available channels and to memorize
automatically
10 RECALL: to show current status
11 TV/PC: to switch between TV and PC screens (This function
may not be feasible if you are not using an AG neovo monitor.)
