Agilent 35670A
GPIB Commands:
Quick Reference
This Quick Reference of the GPIB commands recognized
by the Agilent 35670A lists the common commands and
then lists the subsystem commands in alphabetical order.
Figure 1 shows the Agilent 35670A status registers.
Syntax descriptions use the following conventions:
|
indicates “or”; one and only one of the items can be
chosen
< >
indicates the name of items that need further definition
[]
indicates the enclosed items are optional
~
indicates a valid range of values
Add a “?” to make the query form of a command;
commands listed with a “?” are query only; commands
listed with a “-?” cannot be queried.
A “:” indicates branching points on the command tree.
Use “;” to send multiple commands within a single
program message. The command parser assumes the
second command comes from the same branch as the
preceeding command.
Use “;:” to reset the command parser to the base of the
command tree when sending multiple commands within
a single program message.
The input defaults to channel 1 and the trace defaults to
trace A if the optional [1|2|3|4] parameter is not
specified.
To view the GPIB command which corresponds to a
front panel operation, press [
Local/GPIB
]
[
GPIB ECHO ON OFF
] to highlight ON.
For more information on a particular command
refer to GPIB Programming with the Agilent 35670A.
1
