Part 4: Receiver Options Agilent’s new multi-technology and multi-band receivers support up to four RF bands in a
single compact package. The combination of uplink and downlink bands depends on the
configuration chosen. All receivers include a integral 12 channel GPS and four-port USB
hub. The receivers are listed by option number and by technology with supported bands.
Receivers are all options of the base product W1314A.
Option Number Description
W1314A-100 GSM 900/1800 (UL/DL)
W1314A-110 GSM/CDMA/UMTS 850/1900 (UL/DL)
W1314A-120 GSM450/CDMA450(partial)(UL/DL), GSM 900/1800 (DL) and UMTS 2100 (DL)
W1314A-130 GSM/CDMA/UMTS 850/1900 (DL) and GSM 900/1800 (DL)
W1314A-140 GSM/CDMA/UMTS 850 (DL), GSM 900/1800 (DL) and UMTS 2100 (DL)
W1314A-150 GSM/CDMA/UMTS 850/1900 (DL), UMTS 1700 (UL), CDMA/UMTS 2100 (DL)
W1314A-200 UMTS 2100 (UL/DL) GSM 900/1800 (DL)
W1314A-210 UMTS 2100 (DL), UMTS TDD 2100 (TDD) and GSM 900/1800 (DL) (TDD future
enhancement)
W1314A-220 CDMA/UMTS 1900/2100 (DL), UMTS TDD 2100 (TDD) and CDMA 850 (DL)
(TDD future enhancement)
W1314A-230 CDMA/UMTS 850/2100 (UL/DL)
W1314A-300 iDEN 800/900 (UL/DL)
W1314A-310 iDEN 800/900 (DL), GSM/CDMA/UMTS 850/1900 (DL)
W1314A-410 JCDMA 800 (DL), JCDMA/UMTS 1700 (DL) and UMTS 2100 (DL)
W1314A-500 WiLAN (TDD), GSM 900/1800 (DL) and UMTS 2100 (DL) (WiLAN is CW only at
present)
Table 4a - Digital Receiver Part Numbers - listed by part number.
EExxaammppllee
W1314A-200 supports UMTS at 2100 MHz in both the uplink and downlink bands as
well as GSM 900 and GSM 1800 in the downlink bands only.
NNootteess
Agilent receivers require related receiver measurement software as described in the Software
Options section (refer to Table 1).
Agilent receivers include an internal 12 channel GPS receiver although you can use an alternative
external GPS unit if preferred.
If you require dead reckoning with your GPS, you need to use an external GPS. Agilent offers an
external GPS with dead reckoning capability (refer to Table 6)
You need to select the receiver that covers the frequency bands in which you want to make
measurements.
Each receiver includes the following components:
• Magnetic-mount RF antenna for the corresponding frequency band
• Adaptor for RF antenna connection to receiver
• USB cable for connection to PC
• AC/DC power supply
• DC power cord - cigarette lighter type
• Mounting kit - mounting plate and screws for mounting receiver in a vehicle
