Alcatel-Lucent 1850 TSS-5 Transport Service Switch 7
Versatile Applications
1850 TSS-320
1850 TSS-15/100
1850 TSS-5
BSC/RNC
1850 TSS-5
Hybrid Optical/
Packet Aggregation
Cell Site MTSO Aggregation
Hub/Large Cell-Site
Aggregation
T1/E1 (Native and CES/PW),
Ethernet
T1/E1
Hybrid Optical/
Packet Access
BTS/Node B
BTS/Node B
BTS/Node B
Figure 1. Mobile Backhaul
Mobility Backhaul
The 1850 TSS-5 supports backhaul for all wireless technologies, including:
•CodeDivisionMultipleAccess(CDMA)
•GlobalSystemforMobileCommunications/UniversalMobileTelecommunications
System (GSM/UMTS)
•WidebandCodeDivisionMultipleAccess(W-CDMA)
•WorldwideInteroperabilityforMicrowaveAccess(WiMAX)
Mobility second-generation mobile system (2G) and 3G traffic is accommodated using Ethernet or
SONET/SDH transport. In addition, its aggregation capabilities allow the 1850 TSS-5 to backhaul
multiple parallel networks simultaneously. With a SONET/SDH network, TDM traffic is carried
in native mode and Ethernet is carried by industry-proven Ethernet over SONET/SDH (EoS).
As mobility traffic and applications become increasingly data and IP oriented, Ethernet backhaul
networks become more attractive. The 1850 TSS-5 offers feature-rich Ethernet services of up to
GigE. (see Figure 1).
