AT-2916SX
| PCI Gigabit Fiber Interface Card
Specifications
Management Features
WMI
ACPI 1.1
PXE 2.1 Boot ROM
SNMP
Bus Type
PCI 2.2
Ethernet Standards
IEEE 802.1p Quality of Service
IEEE 802.1Q VLANs
IEEE 802.2 LLC
IEEE 802.3ab Gigabit standard
IEEE 802.3ac MAC
IEEE 802.3ad Link aggregation
IEEE 802.3az 1000SX
IEEE 802.3x Flow control, auto-negotiation
IEEE 802.3z 1000X
Drivers
Supported
Vista
Vista 64-bit
Windows XP
Windows XP 64-bit
Windows 2003
Windows 2003 64-bit
Windows 2000
NDIS2
NetWare 6.x
Linux 2.4
Linux 2.6
SNMP
Available
Windows NT 4
Solaris x86
Solaris Sparc 32-bit
Solaris Sparc 64-bit
NetWare 5.x
Compliance
RoHS
UL
FCC/EN55022 Class B
TUV
EN55024
CE
C-TICK
VCCI
Connectors
SC
LC
Optical input power (min) -17dBm
Transmit optical power (min/max) -9.5/-1.5dBm
Environmental Specifications
Operating temperature 0°C to 50°C
Storage temperature -25°C to 70°C
Relative humidity 5% to 90% non-condensing
Power
Power consumption 3.78 Watts (max)
Signaling voltage 3.3/5V
Status Indicators
1000 ON 1000Mbps link up
OFF 1000Mbps link down
ACT ON Receiving/transmitting
OFF Not receiving/
not transmitting
Physical Characteristics
Dimensions 12cm x 6.4cm
(W x H) (4.7”) x (2.5”)
Ships with standard bracket attached to interface card.
Low-profile bracket is included in packaging.
Network Type
Auto-negotiation full-duplex flow control
Maximum Cabling Distances
Up to 500m with 850 nm multi-mode fiber cable
Up to 220m with 62.5/125 µm multi-mode fiber cable
Up to 500m with 50/125 µm multi-mode fiber cable
Network Controller
Broadcom BCM5703S
Ordering Information
AT-2916SX/AA-xxx
1000SX 32-bit PCI Gigabit Ethernet interface card
Where AA = SC or LC
Where xxx = 001 for single pack
020 for 20-pack
901 for single pack, Federal
and Government
920 for 20-pack, Federal and
Government
Ships with standard bracket attached to interface card.
Low-profile bracket is included in packaging.
