STATUS INDICATORS
UTP Ports:
Link Solid on indicates valid link to hub or switch
Activity Flashing indicates network activity
Speed Solid on indicates 100Mbps operation
Duplex Solid on indicates full duplex operation
PC BUS INTERFACE
Bus Interface PCI Bus 2.1 Compliant
Bus Width 32 bit
Data Transfer mode PCI 2.1 Bus Mastering
Network Mng. Interface DMI 2.0 Support
Power Mng. Interface ACPI
UTP INTERFACE
Connector Shielded RJ-45, MDI
100MBPS FIBER INTERFACE
Connectors ST, SC, MT-RJ or VF-45
Fiber type 62.5/125µM multi-mode fiber
Ouput Power Min -19dB, Typical -16.8dB, Max -14dB
DRIVER SUPPORT
16 bit ODI Netware workstation
32 bit ODI Netware server
NDIS 2.0.1 MSDOS client
NDIS 3.0 miniport Win95 retail
NDIS 4.0 NT 4.0, Win95 OSR2
NDIS 4.0 Fault Tolerance
NDIS 5.0 Win98, Win2000,WinME, WinXP
POWER CHARACTERISTICS
5vDC at 5W (typical)
ENVIRONMENTAL SPECIFICATIONS
Operating Temp. 0°C to 50°C
Relative Humidity 5% to 80% noncondensing
PHYSICAL CHARACTERISTICS
Dimensions 10.7cm x 15.3cm
(4.2” x 6.4”)
half size form factor
Weight 120g (4.2oz)
AT-2700 series low profile cards:
Dimensions 6.5cm x 14.3cm
STANDARDS COMPLIANCE
IEEE 802.3u 10T & 100TX
IEEE 802.3u 100FX
ELECTRICAL/MECHANICAL APPROVALS
FCC class B
VDE class B
CE
USA Headquarters: 19800 North Creek Pkwy, Suite 200, Bothell,WA 98011, USA Tel: 800.424.4284 Fax: 425.481.3895
European Headquarters: Via Motta 24, 6830 Chiasso, Switzerland (Corporate) Tel: (+41) 91 697.69.00 Fax: (+41) 91 697.69.11
(European Sales) Tel: (+39) 02 414.112.1 Fax: (+39) 02 414.112.61
www.alliedtelesyn.com
© 2003 Allied Telesyn,Inc.All rights reserved.Information in this document is subject to change without notice.
All company names,logos,and product designs that are trademarks or registered trademarks are the property of their respective o
wners.
617-00349-00 Rev.D
ORDERING INFORMATION
AT-2700TX
10/100Mbps Autosensing UTP Adapter Card
AT-2700FX/AA
Adapter card with one 100FX connection
AT-2700FX/LP/AA
Low profile adapter card
with one 100FX connection
AT-2700FTX/AA
Adapter card with one 100FX
and one 10/100TX connection
AT-2700FTX/LP/AA
Low profile adapter card with one 100FX
and one 10/100TX connection
Where AA =
ST, SC, MT-RJ or VF-45
20 packs are available for additional savings
AT-2700 Series, Fast Ethernet PCI Adapter Cards
