Blackbird Docking Adapter
PMD-DOK2
• INSTALLATION/OWNER'S MANUAL
Please read this manual to maximize
your enjoyment of the outstanding
performance and feature capabilities
of the equipment, then retain the
manual for future reference.
IMPORTANT
Please record the serial number of your unit in the space provided below and keep it as a permanent record.
The serial number plate is located on the bottom of the unit.
SERIAL NUMBER:_______________________________________________________________________
INSTALLATION DATE:____________________________________________________________________
INSTALLATION TECHNICIAN:____________________________________________________________
PLACE OF PURCHASE:__________________________________________________________________
ALPINE ELECTRONICS, INC.
Tokyo office:
1-1-8 Nishi Gotanda Shinagawa-ku
Tokyo 141-0031, Japan
Tel.: 03-3494-1101
ALPINE ELECTRONICS MARKETING, INC.
1-1-8 Nishi Gotanda, Shinagawa-ku,
Tokyo 141-0031, Japan
Tel.: 03-5496-8231
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place
Torrance, California 90501 U.S.A.
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
7300 Warden Ave. Suite 203, Markham,
Ontario L3R 9Z6, Canada
Tel.: 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.
161-165 Princes Highway, Hallam
Victoria 3803, Australia
Tel.: 03-8787-1200
ALPINE ELECTRONICS GMbH
Frankfurter Ring 117
80807 München, Germany
Tel.: 089-32 42 640
ALPINE ITALIA S.P.A.
Viale C. Colombo 8,
20090 Trezzano Sul
Naviglio (MI), Italy
Tel.: 02-484781
ALPINE ELECTRONICS
(bENELUX) GMbH
Leuvensesteenweg 510-B6,
1930 Zaventem, Belgium
Tel.: 02-725 1315
ALPINE ELECTRONICS FRANCE S.A.R.L.
(RCS PONTOISE B 338 101 280)
98, Rue de la Belle Etoile,
Z.I. Paris Nord II,
B.P. 50016,
95945 Roissy Charles de GaulleCedex,
France
Tel.: 01-48638989
ALPINE ELECTRONICS OF U.K., LTD.
Alpine House
Fletchamstead Highway,
Coventry CV4 9TW, United Kingdom
Tel.: 0870-33 33 763
ALPINE ELECTRONICS DE ESPAÑA, S.A.
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava).
APDO 133, Spain
Tel.: 945-283588
Points to Observe for Safe Usage
• Read this manual carefully before starting
operation and use this system safely. We
cannot be responsible for problems resulting
from failure to observe the instructions in this
manual.
• This manual uses various pictorial displays
to show how to use this product safely and
to avoid harm to yourself and others and
damage to your property. Here is what these
pictorial displays mean. Understanding them is
important for reading this manual.
• Meaning of displays
Warning
This label is intended to alert the
user to the presence of important
operating instructions.
Failure to heed the instructions
will result in severe injury or
death.
Caution
This label is intended to alert the
user to the presence of important
operating instructions.
Failure to heed the instructions
can result in injury or material
damage.
Warning
DO NOT DISASSEMBLE OR ALTER.
Doing so may result in an accident, fire or electric
shock.
USE ONLY IN CARS WITH A 12 VOLT NEGATIVE
GROUND.
(Check with your dealer if you are not sure.) Failure
to do so may result in fire, etc.
DO NOT SPLICE INTO ELECTRICAL CABLES.
Never cut away cable insulation to supply power to
other equipment. Doing so will exceed the current
carrying capacity of the wire and result in fire or
electric shock.
DO NOT INSTALL IN LOCATIONS WHICH MIGHT
HINDER VEHICLE OPERATION, SUCH AS THE
STEERING WHEEL OR GEARSHIFT.
Doing so may obstruct forward vision or hamper
movement etc. and result in serious accident.
DO NOT ALLOW CABLES TO BECOME
ENTANGLED IN SURROUNDING OBJECTS.
Arrange wiring and cables in compliance with the
manual to prevent obstructions when driving. Cables
or wiring that obstruct or hang up on places such as
the steering wheel, gear lever, brake pedals, etc. can
be extremely hazardous.
MAKE THE CORRECT CONNECTIONS.
Failure to make the proper connections may result in
fire or product damage.
Caution
USE SPECIFIED ACCESSORY PARTS AND
INSTALL THEM SECURELY.
Be sure to use only the specified accessory parts.
Use of other than designated parts may damage
this unit internally or may not securely install the
unit in place. This may cause parts to become loose
resulting in hazards or product failure.
DO NOT INSTALL IN LOCATIONS WITH HIGH
MOISTURE OR DUST.
Avoid installing the unit in locations with high
incidence of moisture or dust. Moisture or dust that
penetrates into this unit may result in product failure.
HAVE THE WIRING AND INSTALLATION DONE
BY EXPERTS.
The wiring and installation of this unit requires
special technical skill and experience. To ensure
safety, always contact the dealer where you
purchased this product to have the work done.
ARRANGE THE WIRING SO IT IS NOT CRIMPED
OR PINCHED BY A SHARP METAL EDGE.
Route the cables and wiring away from moving parts
(like the seat rails) or sharp or pointed edges. This
will prevent crimping and damage to the wiring. If
wiring passes through a hole in metal, use a rubber
grommet to prevent the wire’s insulation from being
cut by the metal edge of the hole.
LIMITED WARRANTY
