Filter
Top Products
19
For
SD Memory
Card
For
miniSD™
Card
For
microSD™
Card
For
W-SIM
For
Memory
Stick™
For
Memory
Stick Micro™
Combine Type
For
Express
Card™
For
Compact
Flash™
For PC cards
supporting
CardBus
For CMOS
Camera Module
Style
Dimensions
Cautions
1. This product has been designed and manufactured for use in ordinary electronic equipment, such as AV equipment,
electric home appliances, office machines and communication equipment. In case of using the products for highly
sensitive applications such as medical, aviation, aerospace and security, the set makers shall require to include
measures necessary to meet product safety requirements of such specific applications. Such measure may include
additional protection circuits and redundant circuits, for example.
2. To prevent contact failures caused by sulfuration or oxidation on the contact and terminal or deterioration of
solderability caused by film forming, please follow the instructions given below.
1 Do not store the product in locations with high temperature or high humidity. Keep it in an atmosphere free from
corrosive gases including sulphurous or chlorinate gas. Do not stack.
2 Store the adapter unopened at room temperature and low humidity. Use the product preferably within 3 months
after delivery or within 6 months at the latest.
3 To store the product after opening the package, keep it in a sealed polyethylene bag. Store in a dark, cool place,
out of direct sunlight. Use the product as soon as possible.
F Above dimensions apply when a miniSD™ card is fully inserted into the adapter case.
Indications on the label can be customized individually. For details, please contact us. Samples shall be shipped with
the standard label. Label applied in above diagram is Alps' standard label.
Note
Unit:mm
SD Card Adapter for miniSD™ card
SCJC
Series
