SPECIFICATIONS
Model Numbers
ADMNPLASMA42 . . . . . . . .42-inch Plasma Monitor
ADMNPLASMA46 . . . . . . . .46-inch Plasma Monitor
ADMNPLASMA50 . . . . . . . .50-inch Plasma Monitor
Accessories
ADMMTPLASMAW . . . . . . .Wall flush mount for all models
ADMMTPLASMAP . . . . . . . .Ceiling mount (adjustable height) for all
models
Electrical
Resolution
ADMNPLASMA42 . . . . . . . .852 x 480 (WVGA)
ADMNPLASMA46 . . . . . . . .852 x 480 (WVGA)
ADMNPLASMA50 . . . . . . . .1366 x 768 (WXGA)
Brightness
ADMNPLASMA42 . . . . . . . .375 (cd/m) (w/o filter: 750)
ADMNPLASMA46 . . . . . . . .300 (cd/m) (w/o filter: 700)
ADMNPLASMA50 . . . . . . . .400 (cd/m)
Power Consumption
ADMNPLASMA42 . . . . . . . .AC 100-240V, 50-60Hz, 340 watts
ADMNPLASMA46 . . . . . . . .AC 100-240V, 50-60Hz, 330 watts
ADMNPLASMA50 . . . . . . . .AC 100-240V, 50-60Hz, 370 watts
Viewing Angle . . . . . . . . . . . . . .Over +/- 160º
Mechanical
Dimensions (H x W x D)
ADMNPLASMA42 . . . . . . . .640 x 1033 x 82 mm
(22.5 x 40.6 x 3.2 in)
ADMNPLASMA46 . . . . . . . .686 x 1134 x 98 mm
(27.0 x 44.6 x 3.8 in)
ADMNPLASMA50 . . . . . . . .843 x 1282 x 99 mm
(33.2 x 50.5 x 3.9 in)
Unit Weight
ADMNPLASMA42 . . . . . . . .37.8 kg (83.0 lbs)
ADMNPLASMA46 . . . . . . . .42.0 kg (92.0 lbs)
ADMNPLASMA50 . . . . . . . .52.3 kg (115.0 lbs)
Shipping Information
Dimensions (H x W x D)
ADMNPLASMA42 . . . . . . . .762 x 1194 x 165 mm
(30.0 x 47.0 x 6.5 in)
ADMNPLASMA46 . . . . . . . .940 x 1296 x 216 mm
(37.0 x 51.0 x 8.5 in)
ADMNPLASMA50 . . . . . . . .1067 x 1473 x 229 mm
(42.0 x 58.0 x 9.0 in)
Unit Weight
ADMNPLASMA42 . . . . . . . .41.4 kg (91.0 lbs)
ADMNPLASMA46 . . . . . . . .46.4 kg 102.0 lbs)
ADMNPLASMA50 . . . . . . . .57.8 kg (127.0 lbs)
Inputs/Outputs
One each: PC (D-Sub 15 pin), DVI, S-Video (SVHS), RCA video and audio,
Component video
Regulatory
Emissions . . . . . . . . . . . . . . . . . .FCC: Part 15, Class B
SubPart B: 2002
ICES-003
Safety . . . . . . . . . . . . . . . . . . . . . .UL60950
CSA C22.2
AD PLASMA MONITORS 42, 46 & 50-INCH
Product specifications and availability subject to
change without notice.
Certain product names mentioned herein may be trade
names and/or registered trademarks of other companies.
VS353-03 07/05 L
©2005 Sensormatic Electronics Corporation
Back side – Single sheet – Letter size – print b/w
Warranty Support Procedure:
Please call the manufacturer’s toll free number: 1-800-827-2850, extension 216. Also, an additional 12 month warranty extension is available from the manufacturer, at this number.
