AMERICAN DYNAMICS AD9517B 17-INCH COLOR MONITOR
VS206-02 03/03 A4E
©2003 Sensormatic Electronics Corporation
Product specifications and availability subject to
change without notice.
Certain product names mentioned herein may be trade
names and/or registered trademarks of other companies.
SPECIFICATIONS
Model Number
AD9517B . . . . . . . . . . . . . . . . . . . . . Monitor, Color, 17 in, 280 TV lines
composite, (>750 TVL Y/C), NTSC/PAL
Operational
Picture Tube . . . . . . . . . . . . . . . . . . 43.18 cm (17 inch diagonal), 90°
deflection, flat-square type CRT
Resolution . . . . . . . . . . . . . . . . . . . >750 TV lines Y/C
450 TV lines composite NTSC/PAL
Comb Filter . . . . . . . . . . . . . . . . . . Internal
Video Input Level . . . . . . . . . . . . . 1.0 Vp-p, composite NTSC/PAL
Impedance . . . . . . . . . . . . . . . . . . . HiZ/75 Ω, auto termination
Audio Output . . . . . . . . . . . . . . . .1.0 watt
Front Panel Controls
Phase (Tint) . . . . . . . . . . . . . . . . . . Adjusts picture to obtain most natural
colors (skin tones), NTSC only
Chroma (Color) . . . . . . . . . . . . . . Adjusts depth of saturation of color
Brightness . . . . . . . . . . . . . . . . . . . Adjusts overall shading of picture and
establishes picture brightness
Contrast . . . . . . . . . . . . . . . . . . . . . Adjusts relationship between light and
dark areas of picture
Menu . . . . . . . . . . . . . . . . . . . . . . . . Provides access to the on screen set-up
menu
Volume +/- . . . . . . . . . . . . . . . . . . . Adjusts volume higher and lower
Video A . . . . . . . . . . . . . . . . . . . . . . Selects video input A
Video B and Y/C . . . . . . . . . . . . . . Selects between composite video B and
Y/C input
Under Scan . . . . . . . . . . . . . . . . . . . Switches between normal and under scan
Power . . . . . . . . . . . . . . . . . . . . . . . . Turns monitor on and off
Connectors
Video A & B . . . . . . . . . . . . . . . . . . Two sets of 2 BNC connectors for loop-
through operation with auto termination
Audio A & B . . . . . . . . . . . . . . . . . . Two sets of 2 RCA connectors for loop-
through operation
Y/C Connector . . . . . . . . . . . . . . .Four pin Mini-DIN pair for loop-through
operation
AC Input Connector . . . . . . . . . . IEC 320 type connector for AC input
Power Cables
North American . . . . . . . . . . . . . . NEMA 5-15P, UL, CUL
Continental European . . . . . . . . CEE 7/7, GS*
*UK and Australian power cords ordered separately.
Electrical
Supply Voltage . . . . . . . . . . . . . . .120 - 230 VAC
(50/60 Hz), ±10%
Power . . . . . . . . . . . . . . . . . . . . . . . . 75 watts
Mechanical
Dimensions (H x W x D)
Cabinet . . . . . . . . . . . . . . . . . . . . 33.4 x 39.5 x 41.81 cm
(13.15 x 15.55x 16.46 in)
Rack Mount . . . . . . . . . . . . . . . 39.9 x 48.3 x 40.64 cm
(15.75 x 19 x 16 in)
Unit Weight . . . . . . . . . . . . . . . . . . 19.6 kg (43.21 lbs)
Shipping Weight . . . . . . . . . . . . . 20.4 kg (44.97 lbs)
Color . . . . . . . . . . . . . . . . . . . . . . . . Black
Construction . . . . . . . . . . . . . . . . . Metal cabinet
Environmental
Operating Temperature . . . . . . . 0° to 40° C (32° to 104° F)
Humidity . . . . . . . . . . . . . . . . . . . . 20 to 80% RH (non-condensing)
Storage Temperature . . . . . . . . . . -25° to 50° C (-13° to 122° F)
Regulatory
Emissions . . . . . . . . . . . . . . . . . . . . USA/FCC: Part 15, Subpart B, Class B
CE: EN55022
EN61000 -3-2
EN61000 -3-3
Canada: ICES-003 (Class B)
Meets Australia/New Zealand EMC
Immunity . . . . . . . . . . . . . . . . . . . . CE: EN50130-4
Safety . . . . . . . . . . . . . . . . . . . . . . . . UL: UL1950
CSA: 22.2, No. 950
CE: EN60950: 2000
DHHS: Rules 21 CFR, Subchapter J ROV
Accessories
AD9517RK . . . . . . . . . . . . . . . . . . Rack Mount Kit
