SPECIFICATIONS
Model Number
HS-CM217 . . . . . . . . . . . . . . . . .21-inch color monitor with audio
Operational
NTSC . . . . . . . . . . . . . . . . . . . . . .525 lines, 60 fields/sec
PAL . . . . . . . . . . . . . . . . . . . . . . . .625 lines, 50 fields/sec
Connectors
Y/C (In/Out) . . . . . . . . . . . . . . .4-pin DIN connector x 2 (loop through)
Video (In/Out) . . . . . . . . . . . . .BNC x 4 (loop through)
With Audio Monitor
Audio (In/Out) . . . . . . . . . . . .RCA jack x 4 (loop through)
Audio Input Signal . . . . . . . . .10-150 mVp-p
Audio Amplifier . . . . . . . . . . .1W/8 ohm (include a speaker)
Subcarrier . . . . . . . . . . . . . . . . . .3.579545 Mhz
Frequency . . . . . . . . . . . . . . . . . .4.433618 Mhz
Horizontal Frequency . . . . . . .500 Hz
Vertical Frequency . . . . . . . . . .50 Hz
Comb Filter . . . . . . . . . . . . . . . .Internal
Input Impedance . . . . . . . . . . .75 ohms or higher (switchable)
High Voltage . . . . . . . . . . . . . . .25k V 1.5k V
Convergence . . . . . . . . . . . . . . .Less than 0.1 mm (at the center of display
area)
Band Width . . . . . . . . . . . . . . . .8 MHz
Video Gain . . . . . . . . . . . . . . . . .30 dB
Pattern Resolution
Center . . . . . . . . . . . . . . . . . . . .520 lines
Corner . . . . . . . . . . . . . . . . . . . .480 lines
Linearity
Horizontal . . . . . . . . . . . . . . . .10% max
Vertical . . . . . . . . . . . . . . . . . . .8%
Electrical
*Supply Voltage . . . . . . . . . . . .96-256 VAC 50 Hz/60 Hz
Power . . . . . . . . . . . . . . . . . . . . . .75 watts
Signal . . . . . . . . . . . . . . . . . . . . . .Video signal: 0.714 Vp-p (Composite 1 Vp-p)
Sync. signal: 0.286 Vp-p
*Includes North American and European power cords
Mechanical
Dimension (H x W x D) . . . . .453 x 490 x 501 mm
(17.8 x 19.3 x 19.7 in)
Unit Weight . . . . . . . . . . . . . . . .25.5 kg (56.0 lbs)
Shipping Weight . . . . . . . . . . . .26.5 kg (58.3 lbs)
Front Control . . . . . . . . . . . . . .Power on/off: rocker switch
color/contrast/brightness/tint
volume/language/under scan
Color . . . . . . . . . . . . . . . . . . . . . .Black matte texture coat finish
Construction . . . . . . . . . . . . . . .Steel cabinet with plastic front panel
Picture Tube Dimension . . . . .21-inch (53 cm) diagonal, 0.7 mm stripe
pitch 1.7R flat type, 90 deflection
Environmental
Operating Temperature . . . . .-10° to 50° C (14° to 122° F )
Storage Temperature . . . . . . .-20° to 70° C (-4° to 158° F )
Regulatory
Emissions . . . . . . . . . . . . . . . . . .FCC Part 15, Subpart B, Class B
AMERICAN DYNAMICS HS-CM217 21-INCH FLAT SQUARE SCREEN COLOR MONITOR
