٢۴ | Page
PRODUCT INFORMATION
LCD Panel
model name 2236Vwa
Driving system TFT Color LCD
Viewable Image Size 547mm diagonal
Pixel pitch 0.248mm(H) x 0.248mm(V)
Video R, G, B Analog lnterface & Digital Interface
Separate Sync. H/V TTL
Display Color 16.7M Colors
Dot Clock 148.5 MHz
Resolution
Horizontal scan range 30 kHz - 80 kHz
Horizontal scan
Size(Maximum)
476.64mm
Vertical scan range 55 Hz - 75 Hz
Vertical scan Size(Maximum) 268.11mm
Optimal preset resolution 1920 x 1080 (60 Hz)
Highest preset resolution 1920 x 1080 (60 Hz)
Plug & Play VESA DDC2B/CI
Input Connector D-Sub 15pin & DVI-D
Input Video Signal
A
nalog: 0.7Vp-p(standard), 75 OHM, TMDS
Power Source
100-240V ～，50/60Hz
Power Consumption
Typical < 42 W
Standby < 1 W
USB Downstream port (A type
)
To USB device, loading < 100mA
off timer 0~24hours Select timing to turn off the monitor.
Speakers 2W x 2
Physical
Characteristics
Connector Type 15-pin Mini D-Sub& DVI-D
Signal Cable Type Detachable
Dimensions & Weight:
Height (with base)
396.6 mm
Width
531.3mm
Depth
206mm
Weight (monitor only)
4.35 kg
Weight (with
packaging)
5.8 kg
Environmental
Temperature:
Operating 0° to 40°
Non-Operating -20°to 60°
Humidity:
Operating 10% to 85% (non-condensing)
Non-Operating 5% to 80% (non-condensing)
A
ltitude:
Operating 0~ 3000m (0~ 10000 ft )
Non-Operating 0~ 5000m (0~ 15000 ft )
Preset Display Modes
