46
AUDIO menu
AUDIO menu
From the AUDIO menu, items shown in the table
below can be performed. Select an item using the
▲/▼ cursor buttons, and press the ► cursor button
or the ENTER button to execute the item. Then
perform it according to the following table.
Item Description
VOLUME
Using the ◄/► buttons adjusts the volume.
Low
High
SPEAKER
Using the ▲/▼ buttons turns on/off the built-in speaker.
ON
OFF
When OFF is selected, the built-in speaker does not work.
AUDIO SOURCE
While the image signal from the input port chosen in step (1) is
projected, the audio signal from the input port selected in step
(2) is output to both the AUDIO OUT port and built-in speaker of
this projector. However, the built-in speaker does not work when
SPEAKER is set to OFF.
(1) Choose a picture input port using the
▲/▼ buttons.
Choose AUDIO OUT STANDBY to
select the sound output in the standby
mode.
(2) Select an audio input port or the mute
icon using the ◄/► buttons.
The icons indicate the following;
No.1: AUDIO IN1 port No.2: AUDIO IN2 port
No.3: LAN port No.4: USB TYPE B port
No.5: HDMI port
: mutes the sound
• Audio input from port nos to 5 can only be selected by each of
the picture input ports.
• Even if the projector is in the standby mode, cooling fans may
work and make noises when the built-in speaker is in operation.
• C.C. (Closed Caption) is automatically activated when
is selected
and an input signal containing C.C. is received. This function is
available only when the signal is NTSC for VIDEO or S-VIDEO, or
480i@60 for COMPUTER IN1 or COMPUTER IN2, and when AUTO
is selected for DISPLAY in the C.C. menu under the SCREEN menu
(
52).
HDMI AUDIO
Using the ▲/▼ buttons switches the mode for the HDMI
TM
audio.
Check each of the two modes provided and select the suitable one
for your HDMI
TM
audio device.
1
2
