Knowing the Parts 2
Touchpad and Buttons
The touchpad with its buttons is a pointing device that provides the same functions as a desktop mouse.
A software-controlled scrolling function is available after setting up the included touchpad utility to
allow easy Windows or web navigation.
Display Panel
The display panel functions the same as a desktop monitor. The Notebook PC uses an
active matrix TFT LCD, which provides excellent viewing like that of desktop monitors.
Unlike desktop monitors, the LCD panel does not produce any radiation or flickering, so
it is easier on the eyes. Use a soft cloth without chemical liquids (use plain water if neces-
sary) to clean the display panel.
Keyboard
The keyboard provides full-sized keys with comfortable travel (depth at which the keys can be depressed)
and palm rest for both hands. Two Windows function keys are provided to help ease navigation in the
Windows operating system.
4
5
6
7
8
9
10
Instant Keys
Instant keys allow you to launch frequently used applications with one push of a button. Details are
described in section 3.
CIR (Consumer Infrared) Port
The consumer infrared (IrDA) communication port allows convenient wireless control of the
provided multimedia software in selected models using the provided wireless remote control in
selected models.
ON/OFF TV MUSIC
PICTURESVIDEO
DVD/MENU
BACK SELECT
PLAY/PAUSE
STOP FWDREW
FULL SCREENMUTE
JUMP
VOL CH
OK
RECORD
RADIO
SETUP MENU
Status Indicators
Status indicator details are described in section 3.
11
12
Power Switch
The power switch allows powering ON and OFF the Notebook PC and recovering from STD. Use the
switch once to turn ON and once to turn OFF the Notebook PC. In Windows XP, this button
can also be used to safely turn OFF the Notebook PC. The power switch only works when
the display panel is opened.
Audio Speakers
The built-in stereo speaker system allows you to hear audio without additional attachments. The
multimedia sound system features an integrated digital audio controller that produces rich, vibrant
sound (results improved with external stereo headphones or speakers). Audio features are software
controlled.
Multimedia Control Buttons (on selected models)
The multimedia control buttons allows for convenient controlling of the multimedia application.
(See section 3 for more information).
