2-2 Chapter 2: Setup
2.4 Adjusting the monitor
• For optimal viewing, we recommend that you look at the full face of the
monitor, then adjust the monitor to the angle that is most comfortable for you.
• Hold the stand to prevent the monitor from falling when you change its angle.
• You can adjust the monitor’s angle from -3º to 20º.
It is normal that the monitor slightly shakes while you adjust the the viewing
angle.
-3º~20º
2.5 Installing the monitor to a VESA wall
mount adapter
The foldable stand of the LS221 LCD monitor is specially designed for a VESA wall
mount adapter.
To install the monitor to a VESA wall mount adapter:
1. Have the front of the monitor face down on a table.
2. Press down the button on the arm and fold the stand toward the back of the
monitor until the button rebounds with a click.
3. Fix the monitor on the VESA wall mount adapter using a screw driver to
fasten four screws into the four screw holes on the monitor stand.
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
The VESA wall mount kit (100 mm x 100 mm) is purchased separately.
Button
Screw holes
VESA wall mount
adapter (optional)
