4-20 Chapter 4: BIOS setup
4.4.6 DRAM CMD Skew on Channel A/B [Auto]
These items are adjustable only when you set the DRAM Command Rate item to
[1N] and may help enhancing DRAM stability on 1N mode.
Conguration options: [Auto] [Advance 175ps] [Advance 150ps] [Advance 125ps]
[Advance 100ps] [Advance 75ps] [Advance 50ps] [Advance 25ps] [Normal] [Delay
25ps] [Delay 50ps] [Delay 75ps] [Delay 100ps] [Delay 125ps] [Delay 150ps] [Delay
175ps]
4.4.7 DRAM CLK Skew on Channel A/B [Auto]
Adjusting these items may help enhancing DRAM overclocking ability.
Conguration options: [Auto] [Advance 350ps] [Advance 300ps] [Advance 250ps]
[Advance 200ps] [Advance 150ps] [Advance 100ps] [Advance 50ps] [Normal]
[Delay 50ps] [Delay 100ps] [Delay 150ps] [Delay 200ps] [Delay 250ps] [Delay
300ps] [Delay 350ps]
4.4.8 DRAM Timing Control [Auto]
Conguration options: [Auto] [Manual]
• The following sub-items apprear only when you set the DRAM Timing
Control item to [Manual].
• The conguration options for some of the following items vary depending
on the DIMMs you install on the motherboard.
1st Information: 6-6-6-15-4-36-6-4
The values vary depending on your settings of the following sub-items:
CAS# Latency [ 5 DRAM Clocks]
Conguration options: [ 4 DRAM Clocks] [ 5 DRAM Clocks] [ 6 DRAM Clocks]
[ 7 DRAM Clocks] [ 8 DRAM Clocks] [ 9 DRAM Clocks] [10 DRAM Clocks] [11
DRAM Clocks]
RAS# to CAS# Delay [ 5 DRAM Clocks]
Conguration options: [ 3 DRAM Clocks] [ 4 DRAM Clocks]~[17 DRAM
Clocks] [18 DRAM Clocks]
RAS# PRE Time [ 5 DRAM Clocks]
Conguration options: [ 3 DRAM Clocks] [ 4 DRAM Clocks]~[17 DRAM
Clocks] [18 DRAM Clocks]
RAS# ACT Time [15 DRAM Clocks]
Conguration options: [ 3 DRAM Clocks] [ 4 DRAM Clocks]~[33 DRAM
Clocks] [34 DRAM Clocks]
RAS# to RAS# Delay [Auto]
Conguration options: [Auto] [ 1 DRAM Clocks]~[15 DRAM Clocks]
