4-18 Chapter 4: BIOS setup
The following items appear when you set the DRAM Timing Control item to
[Manual].
DRAM CAS# Latency [ 5]
Conguration options: [3] [4] [5] [6]
DRAM RAS# to CAS# Delay [ 6 DRAM Clocks]
Conguration options: [3 DRAM Clocks] [4 DRAM Clocks] [5 DRAM Clocks]
[6 DRAM Clocks]
DRAM RAS# Precharge [6 DRAM Clocks]
Conguration options: [3 DRAM Clocks] [4 DRAM Clocks] [5 DRAM Clocks]
[6 DRAM Clocks]
DRAM RAS# Activate to Precharge [15 DRAM Clocks]
Conguration options: [9 DRAM Clocks] [10 DRAM Clocks]~[14 DRAM
Clocks] [15 DRAM Clocks]
DRAM Write Recovery Time [Auto]
Conguration options: [Auto] [1 DRAM Clocks] [2 DRAM Clocks]~[14 DRAM
Clocks] [15 DRAM Clocks]
DRAM TRFC [Auto]
Conguration options: [Auto] [20 DRAM Clocks] [25 DRAM Clocks]
[30 DRAM Clocks] [35 DRAM Clocks] [42 DRAM Clocks]
DRAM TWTR [Auto]
Conguration options: [Auto] [1 DRAM Clocks]~[15 DRAM Clocks]
DRAM TRRD [Auto]
Conguration options: [Auto] [1 DRAM Clocks]~[15 DRAM Clocks]
DRAM TRTP [Auto]
Conguration options: [Auto] [1 DRAM Clocks]~[15 DRAM Clocks]
Clock Over-Charging Mode [Auto]
Conguration options: [Auto] [0.70V] [0.80V] [0.90V] [1.00V]
CPU Spread Spectrum [Auto]
Allows you to enable or disable the CPU spread spectrum.
Conguration options: [Auto] [Disabled]
PCIE Spread Spectrum [Auto]
Allows you to enable or disable the PCIE spread spectrum.
Conguration options: [Auto] [Disabled]
