P8B75-M LE Series specications summary
ASUS unique features ASUS Exclusive Features:
- ASUS EPU
- ASUS GPU Boost
- ASUS USB 3.0 Boost
- Network iControl
- MemOK!
- ASUS AI Suite II
- Ai Charger
- ASUS Anti-Surge Protection
- ASUS UEFI BIOS featuring graphics user interface
- All Solid Capacitors (P8B75-M LE PLUS only)
ASUS Quiet Thermal Solution:
- ASUS Q-Fan 2
- ASUS Fan Xpert
ASUS EZ DIY:
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2™
Rear panel I/O ports 1 x PS/2 keyboard port (purple)
1 x PS/2 mouse port (green)
1 x HDMI port (P8B75-M LE only)
1 x DVI-D port
1 x D-Sub port
1 x LAN (RJ-45) port
4 x USB 2.0/1.1 ports
2 x USB 3.0/2.0 ports (blue)
3 x Audio jacks
Internal connectors/
switches/ buttons
1 x USB 3.0 connector supports additional 2 USB 3.0 ports
2 x USB 2.0 connectors support additional 4 USB 2.0 ports
5 x SATA 3.0 Gb/s connectors (blue)
1 x SATA 6.0 Gb/s connector (gray)
1 x CPU fan connector
1 x Chassis fan connectors
1 x COM connector
1 x LPT connector
1 x Front panel audio connector (AAFP)
1 x S/PDIF output connector
1 x System panel connector
1 x Speaker connector
1 x 24-pin ATX power connector
1 x 4-pin ATX 12V power connector
1 x MemOK! button
(continued on the next page)
