3.4 Ai Tweaker menu
The Ai Tweaker menu items allow you to congure overclocking-related items.
Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect eld
values can cause the system to malfunction.
The conguration options for this section vary depending on the CPU and DIMM model you
installed on the motherboard.
Scroll down to display the following items:
Main
Ai Tweaker
Advanced Monitor Boot Tool
Exit
Version 2.10.1208. Copyright (C) 2011 American Megatrends, Inc.
[X.M.P.] When XMP is enabled BLCK
frequency, CPU ratio and memory
parameters will be auto optimized.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
EFI BIOS Utility - Advanced Mode
Target CPU Speed : xxxxMHz
Target DRAM Speed : xxxxMHz
Ai Overclock Tuner Auto
Turbo Ratio Auto
Internal PLL Overvoltage Auto
FreqRef Auto
Memory Frequency Auto
iGPU Max. Frequency Auto
EPU Power Saving Mode Enabled
EPU Setting Disabled
> OC Tuner
> DRAM Timing Control
> CPU Power Management
> DIGI+ VRM
Version 2.10.1208. Copyright (C) 2011 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
CPU Voltage 1.176V Offset Mode
CPU Offset Mode Sign +
CPU Offset Voltage Auto
iGPU Voltage Offset Mode
DRAM Voltage 0.925V Auto
VCCIO Voltage 1.062V Auto
PCH Voltage 1.050V Auto
VCCSA Voltage Auto
CPU PLL Voltage Auto
CPU Spread Spectrum Auto
iGPU Offset Voltage
Auto
