2-8 Chapter 2: RAID conguration
2.2.2 Integrated Mirroring Enhanced volume
The Integrated Mirroring Enhanced (IME) supports three to ten disks, or seven
mirrored disks plus two hot spare disks.
To create an IME volume:
1. Follow steps 1–4 of the section
Integrated Mirroring volume.
2. The
Select New Array Type screen appears.
Use the arrow keys to select Create IME Volume, then press <Enter>.
Esc = Exit Menu F1/Shift+1 = Help
Enter = Choose array type to create
LSI Corp Cong Utility v6.20.00.00 (2007.12.04)
Select New Array Type -- SAS1064E
Create IM Volume Create Integrated Mirror Array of 2
disks plus up to 2 optional hot spares.
Data on the primary disk may be migrated.
Create IME Volume Create Integrated Mirrored Enhanced
Array of 3 to 10 disks including up
to 2 optional hot spares.
ALL Data
on array disks will be deleted!
Create IS Volume Create Integrated Striping array of
2 to 10 disks.
ALL Data
on array disks will be deleted!
3. The Create New Array screen shows the disks you can add to make up the
IME volume.
Integrated Mirroring Enhanced (IME) supports three to ten disks, or seven
mirrored disks plus two hot spare disks. Use the arrow key to select a disk,
then move the cursor to the RAID Disk column. To include this disk in the
array, press <+>, <->, or <Space>.
You may also specify the Hot Spare disk here. Select the disk, then move the
cursor to the Hot Spr column, then press <+>, <->, or <Space>.
Esc = Exit Menu F1/Shift+1 = Help
SPACE/+/- = Select disk for array or hot spare C = Create array
LSI Corp Cong Utility v6.20.00.00 (2007.12.04)
Create New Array -- SAS1064E
Array Type: IME
Array Size(MB): 51498
Slot Device Identier RAID Hot Drive Pred Size
Num Disk Spr Status Fail (MB)
0 SEAGATE ST336754SS 0003 [Yes] [No] ------- ---- 35003
1 SEAGATE ST336754SS 0003
[No] [No] ------- ---- 35003
2 SEAGATE ST336754SS 0003
[Yes] [No] ------- ---- 35003
3 SEAGATE ST336754SS 0003 [Yes] [No] ------- ---- 35003
