”Axis Communications AB is the trade name of the Swedish Parent Corporation and Axis the company brand name.
Axis and device is the company logotype of the Axis group of companies.” IBM and PostScript are registered trademarks of
their respective holders.
We reserve the right to introduce modifications without notice.
Technical
Specifications
UNIX
OS/2
Macintosh
Windows
AXIS NetEye 200
NETWORK SYSTEMS
All systems running TCP/IP and having
a HTTP browser supporting HTTP
version 1.0 or higher and JPEG files.
E.g. Netscape Navigator 1.22 and
Microsoft Internet Explorer 2.0 and
higher.
CAMERA
Illumination: 10-10 000 Lux.
Colors: 16 million.
Color Temperature: 2500-6500 K.
Automatic shutter: 1/50-1/100 000s.
Focal length: 3.8 mm (1/4” ccd), picture
angle 51° horizontal, 39° vertical equal
to 35 mm lens.
Focus: Manual focus, 0,2 inches to infinity.
Depth of field: from 2 feet to infinity.
PROTOCOLS
ARP, RARP, BOOTP, TCP, IP, HTTP,
ICMP and FTP.
INSTALLATION
Assign an IP address via ARP, RARP or
BOOTP and add a web reference to the
built in JPEG files. Scripts for integration
in webservers included (NT and UNIX)
for heavily used websites.
NETWORK MANAGEMENT
Config and status via standard HTTP
browser.
SOFTWARE UPDATES
Flash memory allows central and
remote software updates over the net-
work using FTP over TCP/IP. All soft-
ware upgrades are available via Axis
WWW server and offered free of
charge.
IMAGE RESOLUTION
Images in compressed JPEG color
formats, selectable sizes: 352 x 288 and
172 x 144 pixels. Typical file are sizes
23 Kbytes and 10 Kbytes. Picture angle:
51 deg horizontal, 39 deg vertical.
PERFORMANCE
A full size JPEG file is updated in less
than a second.
NETWORK ATTACHMENT
Ethernet 10baseT, RJ45 (twisted pair).
HARDWARE
CPU: 32-bit RISC processor (ETRAX).
FLASH PROM: 1 Mbyte.
RAM: 1792 kbyte.
AUXILLIARY IN/OUTPUT
Mini-Din 8-poles for external connec-
tor, one relay output and two inputs.
SERIAL CONNECTOR
9 pin DSUB. This is for future added
functionality and requires a future
FLASH software upgrade.
ACCESSORIES
Camera mini-tripod. Delivered with each
unit, using standard camera 1/4 in nut.
Can be used stand alone or mounted
on a wall.
POWER SUPPLY
12V AC, 9.6 VA, via external power
supply (PS-D).
DIMENSIONS
Size Height: 1.9 in/4.8 cm
Width 4.9 in/12.5 cm
Length 6.1 in/15.5 cm
Weight 1.0 lb. /0.5 kg,
excluding power supply.
OPERATING ENVIRONMENT
Temperature 40-105°F /5-40°C
Humidity 20-80% RHG, non-
condensing.
APPROVALS
EMC: FCC Class A
: EN 55022/1987
EN50082- 1/1992
Safety: EN 60950, UL, CSA
Internet/Intranet
