DISTRIBUTION PANEL
Specifications
Approvals: Conforms to ANSI/UL
®
STD 60950-1; CE; S008;Certified to CAN/CSA
STD C22.2 NO 60950-1
Connectors: (8) RJ-11 BASE, numbered 0–7; (8) RJ-11 analog EM0, numbered
8–15; (8) RJ-11 analog EM1, numbered 16–23; (4) RJ-45 digital EM0, numbered
8–11; (4) RJ-45 digital EM1, numbered 16–19; (1) RJ-21 male on the back of the
panel
Size: 3.5"H (2U) x 19"W x 1"D (8.9 x 48.3 x 2.5 cm)
Weight: 2.8 lb. (1.3 kg)
Pinning Specifications
(1) Telco (1) RJ-11 (1) Telco (1) RJ-45 (2) RJ-11
Connector Connector Connector Connector Connectors
1 ....................................3 (Ring) 9 ............3 (SX+) ........................3 (Ring)
26..............(Base 0) ........4 (Tip) 34 ............6 (SX-) ........................4 (Tip) (EM0–8)
10 ............4 (SR+)........................3 (Ring)
2..............(Base 1) ........3 (Ring) 35 ............5 (SR-) (RJ-45–8)........4 (Tip) (EM0–9)
27 ....................................4 (Tip)
11 ............3 (SX+) ........................3 (Ring)
3 ....................................3 (Ring) 36 ............6 (SX-) ........................4 (Tip) (EM0–10)
28..............(Base 2) ........4 (Tip) 12 ............4 (SR+)........................3 (Ring)
37 ............5 (SR-) (RJ-45–9)........4 (Tip) (EM0–11)
4 ....................................3 (Ring)
29..............(Base 3) ........4 (Tip) 13 ............3 (SX+) ........................3 (Ring)
38 ............6 (SX-) ........................4 (Tip) (EM0–12)
5 ....................................3 (Ring) 14 ............4 (SR+)........................3 (Ring)
30..............(Base 4) ........4 (Tip) 39 ............5 (SR-) (RJ-45–10)......4 (Tip) (EM0–13)
6 ....................................3 (Ring) 15 ............3 (SX+) ........................3 (Ring)
31..............(Base 5) ........4 (Tip) 40 ............6 (SX-) ........................4 (Tip) (EM0–14)
16 ............4 (SR+)........................3 (Ring)
7 ....................................3 (Ring) 41 ............5 (SR-) (RJ-45–11)......4 (Tip) (EM0–15)
32..............(Base 6) ........4 (Tip)
(continued on the next page)
