724-746-5500 | blackbox.com
Chapter 2: Overview
Page 9
2.3 What’s Included
• (1) Cable Length Meter
• (1) double-banana to BNC + BNC F to F jack
• (2) test leads
• (2) clips
• (1) carrying pouch
2.4 Hardware Description
Figure 2-1 illustrates the Cable Length Meter.
6. Heavy-Duty
Test Leads
7. Mode Select
Button
8. Copper/Aluminum
Distance Button
9. Down Button
10. Set Wire
Length Button
5. Pair/Single
Conductor Button
4. Power Button
3. Up Button
2. Test Lead
Calibration Button
1. Large LCD Display
Figure 2-1. Cable Length Meter.
