Figure 4-1. Header E1 and E2 (IRQ 4 selected).
Headers E3 and E4 select the (normal) single-interrupt-per-board mode or
the multi-interrupt mode, which allows you to share both interrupts on this
card. The multi-interrupt mode also allows you to share the IRQ signal(s) with
other cards that support multiple interrupts.
Figure 4-2. Headers E3 and E4 in Normal Mode.
E3
E3
E4
MN
2
3
4
5
10
11
12
15
CHAPTER 4: Option Selection
