Installation Steps
1. Disconnect the RJ-45 line from the equipment you wish to protect.
2. If the equipment you wish to protect is metal, plug the surge protector into the unit and attach the ground wire to the unit’s
chassis. If the unit is plastic, connect the ground wire to the electrical outlet ground for the unit.
3. Connect the network-side RJ-45 cable to the surge protector and connect the patch cable included with the surge protector
between the surge protector and the equipment you are protecting.
© Copyright 2010. Black Box Corporation. All rights reserved. Printed in U.S.A. Black Box
®
and the Double Diamond logo are registered trademarks of BB Technologies, Inc. Double Diamond
™
is a trademark of BB Technologies, Inc. Any third-party trademarks appearing in this publication are acknowledged to be the property of their respective owners.
SP060A-R2, rev. 1
