Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
0546−12 Assemblies include all parts shown in frames. 11/27/2007
12
28 499423 Pin−Piston
(Standard)
(Used After Code Date
97011200).
−−−−−−− Note −−−−−
298909 Pin−Piston
(Standard)
(Used Before Code
Date 97011300).
298908 Pin−
Piston
(.005” Oversize)
(Used Before Code
Date 97011300).
29 499424 Rod−Connecting
(Standard)
(Used After Code Date
97011200).
−−−−−−− Note −−−−−
490566 Rod−
Connecting
(Standard)
(Used Before Code
Date 97011300).
32 691664 Screw
(Connecting Rod)
32A 695759 Screw
(Connecting Rod)
(Used After Code Date
00042200).
33 262651S Valve−Exhaust
34 262652S Valve−Intake
35 691270 Spring−Valve
(Intake)
36 691270 Spring−Valve
(Exhaust)
37 694086 Guard−Flywheel
40 692194 Retainer−Valve
43 691997 Slinger−Governor/Oil
−−−−−−− Note −−−−−
691486 Slinger−
Governor/Oil
Used on Type No(s).
0807, 0839, 0888,
1192, 1907, 1910,
1939, 1961, 1977,
2016, 2040, 2332,
2333, 2392, 2393,
2394, 2626, 2644,
3132, 3170, 4305,
4605, 4905, 4906.
45 690548 Tappet−Valve
46 691449 Camshaft
(Used After Code Date
96060200).
−−−−−−− Note −−−−−
492830 Camshaft
(Used Before Code
Date 96060300).
46A 691459 Camshaft
(Counterclockwise)
Used on Type No(s).
0625, 0632, 0659,
0668, 0821, 0823,
0853, 0893, 0905,
1125, 1126, 1175,
1176, 1188, 1191,
1725, 1732, 1762,
1768, 1953, 1954,
1979, 1993, 2005,
2388, 2391, 2396,
2398, 3131, 3172.
−−−−−−− Note −−−−−
691460 Camshaft
(Clockwise)
Used on Type No(s).
1955.
50 497465 Manifold−Intake
51 K272199S Gasket−Intake
54 691650 Screw
(Intake Manifold)
55 691421 Housing−Rewind
Starter
55A 492831 Housing−Rewind
Starter
57 491889 Spring−Rewind Starter
58 280399S Rope−Starter
(Cut To Required
Length)
−−−−−−− Note −−−−−
791362 Rope−Starter
Used on Type No(s).
1945.
59 396892 Insert−Grip
59A 692594 Insert−Grip
60 281434S Grip−Starter Rope
(Pistol Grip)
60A 393152 Grip−Starter Rope
(2 Piece)
60B 494212 Grip−Starter Rope
65 690837 Screw
(Rewind Starter)
78 691108 Screw
(Flywheel Guard)
81 691740 Lock−Muffler Screw
K Included in Engine Gasket Set−Ref. No.358.
D Included in Carburetor Overhaul Kit−Ref. No. 121.
z Included in Carburetor Gasket Set−Ref. No. 977.
∅ Included in Valve Gasket Set−Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
