Before you install
Before you install
For USB Interface Cable Users
Finish
For Wired
Network Cable
Users
(HL-2250DN
only)
For Peer-to-Peer network users
For shared network users
Finish
Finish
For USB Interface Cable Users
Finish
For Wired Network Cable Users (HL-2250DN only)
Finish
Print the Printer
Settings Page
For Mac OS X
Brother CreativeCenter
Get inspired. If you’re using
Windows, double‑click the Brother
CreativeCenter icon on your desktop
to access our FREE web site with
many ideas and resources for
personal and professional use.
Mac users can access Brother
CreativeCenter at this web address:
http://www.brother.com/creativecenter/
The Printer Settings Page lists all
the current printer settings, including
network settings.
Make sure that the front cover
a.
is closed and the power cord is
plugged in.
Turn on the machine and wait until
b.
the machine is in the Ready state.
Press
c. Go three times within 2
seconds. The machine will print
the current printer settings page.
Note
For Network Users
If the IP Address on the Printer
Settings Page shows 0.0.0.0, wait for
one minute and try again.
Note
If you use a specified IP Address
for the machine, you must set the
Boot Method to Static by using
the BRAdmin Light. For more
information, see Changing your
machine’s network settings in the
Network User's Guide.
The installation
is now complete.
Click
g. Next.
Note
When the Brother Support
screen appears, make your
selection and follow the
on‑screen instructions.
Follow the on‑screen instructions until this screen f.
appears. Choose your machine from the list, and then
click OK.
Note
If there is more than one of the same model connected on •
your network, the MAC Address (Ethernet Address) will be
displayed after the model name.
You can find your machine’s MAC Address (Ethernet •
Address) and IP Address by printing out the Printer
Settings Page. See Print the Printer Settings Page on the
right.
Double‑click the e. Start Here OSX icon.
Follow the on‑screen instructions.
Note
It may take a few minutes for installation to
complete.
Install the printer driver
Put the installation d.
CD‑ROM into your
CD‑ROM drive.
Connect the network cable
b.
to the LAN connector
marked with a
symbol
and then connect it to a
free port on your hub.
Make sure the machine c.
power switch is on.
Remove the protective cap
a.
from the LAN connector.
The installation is
now complete.
Click
f. Next.
Note
When the Brother Support screen appears,
make your selection and follow the on‑screen
instructions.
Follow the on‑screen instructions until this e.
screen appears. Choose your machine from
the list, and then click OK.
Double‑click the d. Start Here OSX icon.
Follow the on‑screen instructions.
Note
It may take a few minutes for installation to
complete.
Install the printer driver
Put the installation CD‑ROM into your c.
CD‑ROM drive.
Connect the USB
a.
cable to the USB
connector marked with
a
symbol, and then
connect the cable to your
Macintosh.
IMPORTANT
For the latest drivers and information •
on the Mac OS X you are using, visit
http://solutions.brother.com/.
For Mac OS X 10.4.0 to 10.4.10 users, •
upgrade to Mac OS X 10.4.11 - 10.6.x.
Make sure your machine is plugged in and
your Macintosh is switched ON. You must
be logged on with Administrator rights.
The installation is
now complete.
Follow the
d.
on‑screen
instructions to
complete setup.
Follow the on‑screen instructions until this screen appears. Choose your
c.
machine’s queue, and then click OK.
Note
Contact your administrator if you do
not know the location or the name of
the machine queue on the network.
Click b. Install Printer Driver, and click Yes if
you accept the license agreement.
Install the printer driver
Put the installation CD‑ROM into your CD‑ROM a.
drive. If prompted, select your model and
language.
Note
If the Brother screen does not appear automatically,
go to My Computer (Computer), double‑click the
CD‑ROM icon, and then double‑click start.exe.
TCP/IP
a Client computer
b Also known as “Server” or “Print server”
c TCP/IP or USB
d Machine
Note
If you use a specified IP Address
for the machine, you must set the
Boot Method to Static by using the
BRAdmin Light. For more information,
see Changing your machine’s network
settings in the Network User's Guide.
The installation is
now complete.
Follow the on‑screen instructions to
f.
complete setup.
Note
You can find your machine’s IP Address
and the node name by printing out the
Printer Settings Page. See Print the
Printer Settings Page below.
Click e. Install Printer Driver,
and click Yes if you accept the
license agreement.
Install the printer driver
Put the installation CD‑ROM into your CD‑ROM d.
drive. If prompted, select your model and
language.
Note
If the Brother screen does not appear automatically,
go to My Computer (Computer), double‑click the
CD‑ROM icon, and then double‑click start.exe.
Connect the network cable to the LAN b.
connector marked with a symbol
and then connect it to a free port on
your hub.
Make sure the machine power switch c.
is on.
Remove the protective
a.
cap from the LAN
connector.
TCP/IPTCP/IP
a Router
b Machine
Note
If you are going to connect the
machine to your network, we
recommend that you contact
your system administrator prior to
installation.
The installation is
now complete.
Turn the machine
f.
on, and follow
the on‑screen
instructions to
complete setup.
Connect the USB cable to the USB connector e.
marked with the symbol, and then
connect the cable to the computer.
Follow the on‑screen instructions until d.
this screen appears.
Click c. Install Printer Driver, and click Yes if
you accept the license agreement.
Put the installation CD‑ROM into your CD‑ROM drive. If prompted, b.
select your model and language.
Note
If the Brother screen does not appear automatically, go to My Computer
(Computer), double‑click the CD‑ROM icon, and then double‑click start.exe.
Install the printer driver
Turn off the machine and make sure the a.
USB interface cable is NOT connected to the
machine, and then begin installing the printer
driver. If you have already connected the cable,
disconnect it.
Make sure that your computer is ON and
you are logged on with Administrator
rights.
IMPORTANT
If there are any programs running, close •
them.
The screens may differ depending on •
your operating system.
Note
For Windows Vista•
®
and Windows
®
7
users, when the User Account Control
screen appears, click Allow or Yes.
Depending on your security settings, a •
Windows Security or antivirus software
window may appear when using the
machine or its software. Please allow or
permit the window to continue.
XML Paper Specification Printer Driver•
The XML Paper Specification Printer
Driver is the most suitable driver when
printing from the applications that use
the XML Paper Specification documents.
Please download the latest driver by
accessing the Brother Solutions Center at
http://solutions.brother.com/.
For Windows
®
IMPORTANT
DO NOT connect the printer to a USB port on a •
keyboard or a non-powered USB hub.
Connect the printer directly to your computer.•
Make sure the machine power switch is on.b.
You can download the latest drivers and utilities for your machine from
the Brother Solutions Center at http://solutions.brother.com/.
