42
CHECK SETTING IN
LABEL TYPE MODE!
• This message appears if you
try to change the settings for
the Length function or
Frame function after a Label
Type mode with a preset
label length or frame has
already been selected.
• Select a different Label
Type mode.
On 3/4" (18 mm) tape:
CHECK THE NUMBER
OF LINES! 5 MAX
On 1/2" (12 mm) tape:
CHECK THE NUMBER
OF LINES! 3 MAX
On 3/3" (9 mm) and 1/4" (6
mm) tape:
CHECK THE NUMBER
OF LINES! 2 MAX
• This message appears if you
try to print or use the
Preview function when the
number of lines in the text is
greater than the maximum
possible for the installed
tape.
• Reduce the number of lines
or install a wider tape.
CHOOSE COPIES
LESS THAN 1000!
• This message appears if
more than 1000 copies were
selected with the Print
Option functions.
• Note the number of copies
plus the number of
sequential labels cannot
exceed 1000.
• Select less than 1000 copies.
CUTTER ERROR!
• This message appears if the
tape cutter button was
pressed in when
p was
pressed or the tape was
being fed.
• Release the tape cutter
button. If
p was pressed,
press
f to feed out any
printed tape.
• If the problem cannot be
corrected, contact your
service representative.
INPUT WHOLE
CODE!
• This message appears if the
required number of digits is not
entered in the bar code data.
• Input the correct number of
digits or change the bar code
protocol.
Error Message Cause Solution
