For Windows
®
Wired Network Interface Cable / Peer-to-Peer Network
Users (HL-3150CDN / HL-3150CDW / HL-3170CDW)
9
Before you install
a Router
b Machine
a Make sure your computer is ON and you are
logged on with Administrator rights.
b Remove the protective cap from the Ethernet
port marked with a symbol on your
machine.
c Connect the network interface cable to the
Ethernet port, and then connect it to a free port
on your hub.
d Make sure your machine is turned on.
10
Install the printer driver
a Put the CD-ROM into your CD-ROM drive. If
prompted, select your model and language.
b Click Install Printer Driver, and click Yes if
you accept the license agreement.
c Choose Wired Network Connection
(Ethernet), and then click Next.
d Choose Brother Peer-to-Peer Network
Printer, and then click Next.
IMPORTANT
• If there are any programs running, close them.
• The screens may differ depending on your
operating system.
NOTE
If you are going to connect the machine to your
network, we recommend that you contact your
system administrator prior to installation.
TCP/IPTCP/IP
NOTE
• If the Brother screen does not appear
automatically, go to Computer (My
Computer), double-click the CD-ROM icon,
and then double-click start.exe.
• For Windows Vista
®
, Windows
®
7 and
Windows
®
8 users: when the User Account
Control screen appears, permit the window to
continue the installation.
NOTE
For HL-3170CDW: to install the PS driver
(BR-Script3 printer driver), choose Custom
Install, and then follow the on-screen
instructions.
