1.4 Basic Specications
Printing Method Direct line thermal printing
Printing Speed Max. 100mm/sec
Resolution 203 DPI x 203 DPI
Print width 72mm, 576dot
Character ALPHA NUMERIC Character, Extension Character
18 codepages, 14 international characters
Font Font A (12 x 24 dot), Font B (9 x 17 dot)
Number of columns 48 (Font A), 64 (Font B)
Barcode EAN-8, EAN-13, Code39, ITF, UPC-A, Codabar,
Code93, Code128, PDF417(2D), MAXICode(2D)
Emulation ESC/POS, CPCL, Command Compatible
Driver Window CE 4.2&5.0, Window Mobile 5.0
Sensor Paper End Sensor, Gap Sensor, Cover Open Sensor,
Black Mark Sensor
Paper Paper type Thermal Paper
Width 25.4mm ~ 79mm
Thickness 0.06mm ~ 0.09mm
External Diameter
Max.
Φ
56mm
Internal Diameter
12.5mm +/-0.5mm
Reliability Thermal Head 50km
Battery Continuous printing for 90min
Standby for 24hours
Printing length: 162m
Communications Standard Serial(RS-232C), USB, Bluetooth Class2 (CMP-30BT),
Wireless Lan 802.11b/g (CMP-30WF)
MSR (Optional) Card Standard ISO7811/2
Track Track1, Track2, Track3
Magnet Head Life
300,000 Passes (minimum)
IC CARD (Optional) EMV level one certified smart card reader
Battery Charger Input AC100~240V, 50/60 Hz
Output 8.4V , 800~1200mA
Battery Battery type Li-ion
Output 7.4V, 2200mAh
Charging time 2.5 hours
Size 120(W) x 152(D) x 70(H) mm
4.7(W) x 5.9(D) x 2.7(H) inch
Weight 0.6kg
Environmental sealing IP42
Temperature Operation -10 ~ 50
℃
Storage -20 ~ 60
℃
Humidity Operation 35 ~ 95%
Storage 10 ~ 95%
