OWNER’S MANUAL
In extremely cold temperatures, the movement of the picture may be slow
and the picture may be dark, but this is not a malfunction. The set will work
normally once the temperature increases.
Small black and shiny dots inside the liquid crystal panel are normal for liquid
crystal product.
DESCRIPTION
The VMA5091 is a TFT active matrix color LCD monitor which delivers a striking
picture and superior image resolution. The VMA5091 can be used to enjoy video
images with the Clarion video sources, even if no TV tuner is connected.
PACKAGE CONTENTS
5" monitor
Headrest Mounting Bezel
Two Trim Rings
5m long cable with 3 male connectors (Video, Power/Ground, 3.5m IR)
Hardware (One 1/4-20 with nut and washer)
BUTTON AND CONNECTOR LOCATIONS
51
3 2
6
4
7
8
9
1 Power Button
2 IR Sensor
3 Picture Select Down
4 Picture Select Up
5 Picture Control Button
6 8 Pin DIN Pigtail
7 Video Input
8 Power Connector
9 IR Remote Out
