System Unit
Dimensions
(HxWxD)
1.26 (at front) x 14.64 x 10.01 in
32.0 (at front) x 371.8 x 254.3 mm
Weight
Starting at 5.5 lb (2.49 kg)
NOTE:
Height varies depending upon where on the notebook the measurement is made. Weight
varies by configuration and components. Weight includes 6-cell battery, 160GB hard drive,
1 GB memory, and optical drive. Weight varies by configuration and components.
Stand-Alone Power
Requirements
Normal Operating
Voltage
18.5 V
Average Operating
Power
Models with integrated graphics: 17.6 W
Models with discrete graphics: 19.6 W
Max Operating Power
< 90 W
Temperature
Operating
32° to 95° F (0° to 35° C) (not writing optical)
41° to 95° F (5° to 35° C) (writing optical)
Non-operating
-4° to 140° F (-20° to 60° C)
Relative Humidity
Operating
10% to 90%, non-condensing
Non-operating
5% to 95%, 101.6° F (38.7° C) maximum wet
bulb temperature
Shock
Operating
125 G, 2 ms, half-sine
Non-operating
200 G, 2 ms, half-sine
Random Vibration
Operating
0.75 grms
Non-operating
1.50 grms
Altitude
(unpressurized)
Operating
-50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating
-50 to 40,000 ft (-15.24 to 12,192 m)
Industry Standard
Certifications
UL
Yes
CSA
Yes
FCC Compliance
Yes
ENERGY STAR®
Yes
*
EPEAT
Gold
**
ICES
Yes
Australia / NZ A-Tick
Compliance
Yes
CCC
Yes
Japan VCCI Compliance
Yes
MIC
Yes
BSMI
Yes
CE Marking Compliance
Yes
BNCI or BELUS
Yes
CIT
Yes
GOST
Yes
Saudi Arabian
Compliance (ICCP)
Yes
SABS
Yes
UKRSERTCOMPUTER
Yes
* Configurations of the Compaq 610 that are ENERGY STAR qualified are identified as Compaq
610 ENERGY STAR on HP websites and on
www.energystar.gov
.
** EPEAT registration varies by country. See
www.epeat.net
for registration status by country.
EPEAT status listed above applies to U.S.
QuickSpecs
Compaq 610 Notebook PC
Technical Specifications
DA - 13304 Worldwide QuickSpecs — Version 5 — 9.15.2009
Page 10
